Pagina 1/2
1. Attach the le wing to the
back body piece by sliding the
holes in the wing over the pegs
on the back body piece.
2. Attach the right wing to the back body
piece by sliding the holes in the wing
over the pegs on the back body piece.
Insert the lower beak into the head
by pushing the ball into the socket.
4. Insert the base of the
neck into the slot on the
back body piece.
6. Place the front body piece
(with the motor facing
downward) onto the back
body piece, pushing all of
the pegs all the way into all
of the holes. Make sure the
wires t neatly into the
back body compartment.
5. Attach the propeller to
the end of the motor
sha and screw it in place
with the small, thin screw
(part 13).
Note: This is
the smallest
screw in the kit.
7. Screw in the four
small screws (part
14), securing the
body pieces
together.
8. Insert two AAA batteries (1.5-volt, type LR03) into the battery compartment.
Attach the battery compartment cover by rst inserting the tab into the slot in the
body, then pressing the cover gently into place, and nally screwing in the screw.
(The screw is already installed in the battery compartment cover.)
Please provide your child with assistance and support when assembling the ying
pterosaur model. The model must be installed by an adult and operated under adult
supervision. Before starting the assembly and installation, read through the manual
together and be sure to follow it. Please be careful not to let any parts of the kit get
into the hands of small children, especially the small parts and long cable.
ARNING! Not suitable for children under 3
ars. Choking hazard — small parts may be
allowed or inhaled. Strangulation hazard —
g cable may become wrapped around the
. This kit contains functional sharp edges or
s. Do not injure yourself!
ing: This toy is only intended for use by
en over the age of 6 years, due to accessible
nic components. Instructions for parents
or caregivers are included and shall be followed.
Keep packaging and instructions as they contain
important information.
Store the experiment material, particularly the
battery-powered motor and assembled model out
of the reach of small children.
Make sure the model is securely attached to the
ceiling before use.
Do not allow your hair, ngers, or other body
parts to come near the motor-driven propeller.
Safety for Experiments with Batteries
• To operate the models, you will need two AAA
batteries (1.5-volt, type LR03), which could
not be included in the kit due to their limited
shelf life.
• An adult should insert and change the batteries.
For instructions on how to insert and change
the batteries, see step 8.
• The batteries are to be inserted with the correct
polarity (+ and -). Press them gently into the
battery compartment.
• The supply terminals are not to be short-
circuited. A short circuit can cause the wires to
overheat and the batteries to explode.
• Dierent types of batteries or new and used
batteries are not to be mixed.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Always close battery compartments with the
lid.
• Non-rechargeable batteries are not to be
recharged. They could explode!
• Rechargeable batteries are only to be charged
under adult supervision.
• Rechargeable batteries are to be removed from
the toy before being charged.
• Exhausted batteries are to be removed from the
toy.
• Dispose of used batteries in accordance with
environmental provisions, not in the household
trash.
• Be sure not to bring batteries into contact with
coins, keys, or other metal objects.
• Avoid deforming the batteries.
• Have an adult check the model before use to
make sure it is assembled properly. Always
operate the motorized model under adult
supervision. Aer you are done experimenting,
remove the battery from the battery
compartments.
Notes on Disposal of Electrical and Electronic
Components
The electronic components of this product are
recyclable. For the sake of the environment, do
not throw them into the household trash at the
end of their lifespan. They must be delivered to a
collection location for electronic waste,
as indicated by the following symbol:
Please contact your local authorities for
the appropriate disposal location.
With this kit, you will build and y a model of a pterosaur, an order of
prehistoric ying reptiles related to the dinosaurs. This specic
pterosaur is called the Quetzalcoatlus (pronounced “ket-suhl-kow-at-
luhs”). It was the largest ying animal of all time; a huge, bird-like
creature with a 36-foot wingspan, a massive beak, and erce talons. A
battery-powered motor propels your Quetzalcoatlus through the air
while a thin cable keeps it soaring along a circular ight path. Learn how
the propeller makes the model y, about the similarities between
pterosaurs and modern-day birds, and all about this awe-inspiring giant
of the prehistoric skies.
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS CONTINUEDDEAR PARENTS AND ADULT SUPERVISORS
SAFETY INFORMATION
YOUR OWN FLYING PTEROSAUR
FLYING PTEROSAUR
QUETZALCOATLUS
1
2
4
5
6
7
8
3
Tab
+
+
–
–
13
USA: support@thamesandkosmos.com
or 1-800-587-2872
UK: support@thamesandkosmos.co.uk
or 01580 713000
WWW.JURASSICWORLD.COM
© Universal City Studios LLC and Amblin
Entertainment, Inc. All Rights Reserved.
1st Edition 2022 Thames & Kosmos, LLC, Providence, RI, USA
Thames & Kosmos® is a registered trademark of Thames &
Kosmos, LLC. This work, including all its parts, is copyright
protected.
Distributed in North America by Thames & Kosmos, LLC.
Providence, RI 02903 Phone: 800-587-2872;
Web: www.thamesandkosmos.com
Distributed in United Kingdom by Thames & Kosmos UK
LP. Cranbrook, Kent TN17 3HE Phone: 01580
713000; Web: www.thamesandkosmos.co.uk
We reserve the right to make technical changes.
Printed in China
KIT CONTENTS
1. Le wing
2. Right wing
3. Back body piece
4. Front body piece
(with motor, switch,
and battery
compartment)
5. Propeller
6. Head
7. Lower beak
8. Battery
compartment
cover (with small,
at-head screw)
9. Ceiling bracket
10. Hanger
11. Hook
12. Cable
13. Small, thin
screw for
propeller
14. Small screws
for model (4)
15. Large screws
for ceiling (3)
YOU WILL ALSO NEED
2 AAA batteries (1.5-volt, type LR03), small
Phillips-head screwdriver, large Phillips-head
screwdriver (preferably powered), scissors
Experiment Manual
TIP! Handle the motor circuit
assembly very gently. The soldered
connection points can break under
too much stress. Do not push or pull
on the wires. They might break o.
Do you have any questions?
Our tech support team will
be glad to help you!
9
1
13
14
15
4
5
2
11
10
7
6 3 8 12
14 x4
