Pagina 1/20
1 / 20
Copyright © 20 Toshiba Corporation. All Rights R16 eserved.
Client SSD SG5 Series Brochure Rev.1.00
Products and specifications discussed herein are for reference purposes
only and are subject to change without notice. ll information discussed A
herein is provided on an “as is” basis, without warranties of any kind.
Before creating and producing designs and using, customers must refer to
and comply with the latest versions of the product specifications.
SSD
SPECIFICATIONS
Refer to the notes on the next page
Standard Models - 2.5 inch M.2 2280-S2
(Single-sided)
M.2 2280-D2
(Double Sided)-
Memory
TOSHIBA TLC NAND Flash Memory
Interface
SATA revision 3.2
Maximum Speed
6 Gbit/s, 3 Gbit/s, 1.5 Gbit/s
Connector Type
Standard SATA
M.2 B-M
Formatted Capacity
1)
128/256/512/1024 GB
128/256/512 GB
1024 GB
Command
ACS-3
Performance
1),2)
Sequential
Read
up to 545 MB/s {520 MiB/s}
Sequential
Write
up to 387 MB/s {370 MiB/s}
Sector Size
Advanced Format: 4K physical sectors with 512 byte emulation (512e)
Supply Voltage
5.0 V ±5 %
3.3 V ±5 %
Power Consumption
Active: 5.6 W typ.
Idle: 70 mW typ.
Active: 4.0 W typ.
Idle: 65 mW typ.
Active: 5.5 W typ.
Idle: 65 mW typ.
Temperature
Operating: 0 °C 70 °C-
(case temperature)
Non operating: - -40 °C 85 °C-
Operating: 0 °C 80 °C -
(components temperature)
Non operating: - -40 °C 85 °C-
Reliability3)
Mean Time to Failure (MTTF): 1,500,000 hours
Product Life: Approximately 5 years
Size
100.0 mm x 69.85 mm
x 7.0 mm
80.0 mm x 22.0 mm
x 2.23 mm
80.0 mm x 22.0 mm
x 3.58 mm
Weight
48
–
51 g typ.
7 g typ.
8.7 g typ.
More Features
Toshiba's proprietary correction technology, QSBC support. -error
Read only mode supported for emergency.
Compliance
UL/cUL, TÜV, KC, FCC, BSMI, CE, RCM, ISED, VCCI
SG5 SERIES
CLIENT SSD
SG5 s series are Client SSD using Toshiba TLC NAND flash memory.
Delivering a storage capacity up to 1,024GB and a 6.0 Gbit/s SATA interface, the SG5 SSDs
are engineered for desktop and notebook PCs.
Further features of the series include QSBC ECC technology from Toshiba for error
c orrection and reliability.
The versatile SG5 SSD family is also available in thin, space saving M.2 2280 form factor
and standard 2.5- inch type case.
Product image may represent a design model
APPLICATIONS
• Desktop PCs
• Notebook PCs
KEY FEATURES
• Capacities up to 1024GB
• 3- - -bit per cell NAND Flash Memory
• SATA 6.0 Gbit/s interface
• 2.5-inch and M.2 2280 form factor options
• Toshiba Proprietary Quadruple Swing By Code -
(QSBC) ECC
Probleemoplossing Toshiba SSD M.2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Gewicht: | 7 g |
| Breedte: | 22 mm |
| Diepte: | 80 mm |
| Hoogte: | 2.23 mm |
| Interface: | SATA III |
| Temperatuur bij opslag: | -40 - 85 °C |
| Luchtvochtigheid bij opslag: | 5 - 95 procent |
| SSD capaciteit: | 512 GB |
| SSD-vormfactor: | M.2 |
| Mean time between failures (MTBF): | 1500000 uur |
| Type geheugen: | TLC |
| Vermogensverbruik (avg): | 4 W |
| Operating voltage: | 3.3 V |
| Leessnelheid: | 545 MB/s |
| Schrijfsnelheid: | 262 MB/s |
| Component voor: | Notebook |
| Overdrachtssnelheid: | 6 Gbit/s |
| Schokbestendigheid: | 1500 G |
| Trillingen, in bedrijf: | 20 G |
| Bedrijfstemperatuur (T-T): | 0 - 80 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 90 procent |
| Stroomverbruik (idle): | 0.065 W |
