Table of Contents Rev. 5/28/2025 AHSN, MANUAL
Table of Contents Vestil Manufacturing Co. Page 1 of 26
AHSN-Series Knockdown, Steel, Adjustable-Height Cranes
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestil.com info@vestil.com
Table of Contents
Page
Table of Figures
Page
Specifications…………………
2, 3
Fig. A Exploded View: AHSN-2-10-12, 2-10-14, & 2-10-16…
5
Signal Words……..……………
4
Fig. B Exploded View AHSN-2-15 series…………..…….….…
6
Safety Instructions………..…..
4
Fig. C Exploded View AHSN-2-20-12, 2-20-14, & 2-20-16.…
7
Assembling the Crane…........
18, 19, 20, 21
Fig. D Exploded View AHSN-4-10-12, 4-10-14, & 4-10-16.…
8
Using the Crane…..…………..
22, 23
Fig. E Exploded View AHSN-4-15 series…….…………………
9
Festoon Kit……………………..
23
Fig. F Exploded View AHSN-4-20-12, 4-20-14, & 4-20-16..…
10
Record of Satisfactory
Fig. G Exploded View AHSN-6-10-12, 6-10-14, & 6-10-16.…
11
Condition…………………..…..
24
Fig. H Exploded View AHSN-6-15 series………………………
12
National Standards…………..
24
Fig. I Exploded View AHSN-6-20-12, 6-20-14, & 6-20-16...…
13
Inspections & Maintenance..
24
Fig. J Exploded View AHSN-8-10-12, 8-10-14, & 8-10-16…..
14
Labeling Diagram….…………
25
Fig. K Exploded view AHSN-8-15 series………………….……
15
Limited Warranty…………......
26
Fig. L Exploded view AHSN-8-20-12, 8-20-14, & 8-20-16…...
16
Fig. M Exploded view AHSN-10-15-10…………………...……
17
