Table of Contents Rev. 03/2025 COLA MANUAL
T
able of Contents Copyright 2019 Vestil Manufacturing Corp. Page 1 of 19
Alternating Tread Cross-Over Ladders: COLA
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill of lading. If
the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, use, and maintenance comply with laws,
regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Assistance:
If you have questions that are not addressed in these instructions and to order replacement parts, labels, and
accessories, call (260) 665-7586 and ask for the Service and Parts Department. The department can also be
contacted online at http://www.vestilmfg.com/parts_info.htm.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
http://www.vestilmfg.com/ e-mail: info@vestil.com
Table of Contents
Signal Words……….………………..................................................................................................................................... 2
Hazards……....................................................................................................................................................................... 2
Assembling the Ladder…………………………………………………………………………………………….…………. 3, 4, 5
Record of Satisfactory Condition…………………………………………………………………………………………………... 5
Inspections and Maintenance……………………………………………………………………………………………………… 5
Exploded View, Bill of Materials, & Specifications: COLA-2………………………..………………………………………. 6, 7
Exploded View, Bill of Materials, & Specifications: COLA-3………………………..………………………………………. 8, 9
Exploded View, Bill of Materials, & Specifications: COLA-4………………………..…………………………………….. 10, 11
Exploded View, Bill of Materials, & Specifications: COLA-5………………………..…………………………………….. 12, 13
Exploded View, Bill of Materials, & Specifications: COLA-6………………………..…………………………………….. 14, 15
Exploded View, Bill of Materials, & Specifications: COLA-7………………………..…………………………………….. 16, 17
Labeling Diagram…….……………………………………………………………………………………………………..……… 18
Limited Warranty…………………………………………………………………………………………………………………… 19
Photo of model COLA-5-56-20
