TABLE OF CONTENTS REV. 8/15/2024 DCR-205 MANUAL
TABLE OF CONTENTS Copyright 2024 Vestil Manufacturing Page 1 of 13
FORK-MOUNTED DRUM HANDLERS
DCR-205-8; DCR-205-8-DC; DCR-205-12-DC; DCR-205-15; DCR-205-20
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered, record a
complete description of it on the bill of lading. If the product is undamaged, discard the
packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and
maintenance comply with laws, regulations, codes, and mandatory standards applied where
the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts,
labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
department can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-manuals.php.
VESTIL MANUFACTURING COMPANY
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestil.com info@vestil.com
Table of Contents
Page
Signal Words….…………………………………………………………………………………………….
2
Safety Instructions……………………………………………………………..…………….…………….
2
Specifications………………………….…………………..…………………………………………….…
3
National Standards………………………………………………………………………………………..
3
FIG. 1: DCR-205-08-DC Exploded View & Bill of Materials…………………...…………………..…
4
FIG. 2: DCR-205-08 Exploded View & Bill of Materials………...……………...…………………..…
5
FIG. 3: DCR-205-12-DC Exploded View & Bill of Materials……..…………………………..………..
6
FIG. 4: DCR-205-15 Exploded View & Bill of Materials…………………………………………….…
7
FIG. 5: DCR-205-20 Exploded View & Bill of Materials………………………………………………
8
Using the Carrier: Manual Models..………………………….…………………………………………
9
Using the Carrier: Powered Models……………………………………………………………….……
10
Record of Satisfactory Condition………………………………………………………………………
10
Inspections and Maintenance……………………………………………………………………….…
11 - 12
Labeling Diagram……...………………………………………………………………………………….
12
Limited Warranty…...……………………………………………………………………………………...
13
