PRODUCT MANUAL
Designed, Manufactured and Supported in the USA
C O M M U N I C AT I O N & S E C U R I T Y S O L U T I O N S
E-35/E-35-EWP
Handsfree Speaker Phone
with Dialer and Color
Video Camera
May 9, 2018
VIKING
Features
Applications
Specifications
Handsfree Speaker Phone with Built-In
Auto-Dialer and Color Video Camera
The E-35 is a weather and vandal resistant handsfree video phone
designed to provide quick and reliable handsfree communication
and CCTV video of who is at your door or gate. The can beE-35
connected directly to a C.O. line, analog PABX/KSU station, or a
Viking Door/Gate Controller: , or .C-200 C-250 C-2000B
The E-35 features non-volatile memory, a built in dialer, a built-in
high resolution color video camera, and intelligent call progress
detection for automatic hang-up when the call is completed.
The E-35 can be programmed to dial up to 5 different numbers on
ring no answer or busy and can be configured to dial these
numbers until answered.
The E-35-EWP shares all of the features of the in addition toE-35
Enhanced Weather Protection (EWP) for outdoor installations
where the unit is exposed to precipitation or condensation. EWP
products feature foam rubber gaskets, sealed connections, gel-
filled butt connectors, as well as urethane or thermal plastic potted
E-35 / E-35 -EWP
Brushed 316 Stainless Steel
E-35 shown with
optional VE-5x5
circuit boards with internally sealed, field-adjustable trim pots and
DIP switches for easy on-site programming. For more information,
see .DOD 859
Dimensions: Overall-5” x 5” x 2.25” (127mm x 127mm x 57mm),
Plastic Electrical Box-4” x 4” x 2.12” (102mm x 102mm x 54mm)
Shipping Weight: 2 lbs (0.9 Kg)
Operating Temperature: -30°F to 150°F (-34°C to 65°C)
Connections: (5) gel-filled butt connectors (3M Scotchlok UR2)
(See page 2 for complete specifications)
Gate and Door Entry Phones for:
• Business lobbies • Residences
• Auto or pedestrian gates
Non-ADA Hot-Line Phones for:
• Elevators • Stadiums
• Parking lots/ramps • Convention centers
• ATM machines
• Silent holdup alarm dialer using optional Panic Button Kit
CAUTION - When installing on an analog extension of a phone system: Some
phone systems do not conform to analog telecom standards and might not be
compatible with the speaker phones. For a detailed description of the telephoneE-35
line specifications required for any of the phones, see DOD# 869. E-35
Note: In louder background noise environments, the push to talk version may be
required ( or E-30-PT E-30-PT-EWP).
• New Automatic Noise Cancelling feature for proper
operation in noisy environments
• Built-in 5 number auto-dialer
• Built-in high resolution color video camera with wide viewing
angle, tilt/swivel adjustments and wide operating temperature
• Audio and video transmission on one CAT5E cable (page 5)
• Vandal Resistant Features: 14 gauge louvered 316 stainless
steel faceplate with permanent laser etched graphics,
stainless steel speaker/mic screen, heavy duty metal “Call”
button, impact and scratch resistant camera lens and hex
drive mounting screws
• Marine grade 316 stainless Weather Resistant Features:
steel faceplate, Mylar speaker, faceplate gasket, mic and
speaker gasket, internally sealed (IP67) push button switch,
sealed camera lens, potted camera circuit board, stainless
steel phone and camera mounting hardware
• is designed to meet IP66 Ingress Protection Rating E-35-EWP
(see for more information)DOD 859
• Blue “off-hook” LED
• Volume adjustments for microphone and speaker
• Advanced call progress detection: disconnects on busy
signal, return to dial tone, CPC, reorder signal, maximum
call time out and selectable silence time out
• Selectable auto-answer feature for monitoring
• Selectable push button disconnect
• Optional surface mount box availableVE-5x5
• Selectable maximum call time
• Selectable VOX switching speed
• Optional Panic Button Kit ( )PB-1 DOD 233
Information: 715-386-8861
