WET TANTALUM CAPACITORS FOR
HIGH RELIABILITY
DID YOU KNOW?
MS7509-1801
www.vishay.com
© 2018 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED.
Wet tantalum capacitors are the capacitor of choice for space, military, down-hole drilling, and other high
reliability applications. Vishay is the global leader in this technology and offers the broadest portfolio, as well
as the industry’s leading performance families.
Here are wet tantalum capacitors are the ideal solution for high reliability and harsh six reasons
environment applications:
Vishay wet tantalum capacitor capabilities:
• Capacitance values from 1.7 µF to 72 000 µF
• Voltage range from 6 V to 150 V
• 300 thermal shocks, -55 ºC to +125 ºC
• 500 g mechanical shock
• 80 g sine wave vibration, 54 g random vibration
• Both tin / lead and 100 % tin RoHS-compliant terminations are available
• Meet NASA radiation-tolerant testing requirements
• Can operate at altitudes up to 150 000 feet
• Production experience since 1926
• Vishay wet tantalum technology is the best of Sprague, Philips, Tansitor, Mallory,
and Arcotronics
Low DC leakage. For example,
the 135D series offers DCL
values down to 1 µA at 25 °C
• This increases battery life and
reduces power consumption
in DC circuits
• The internal electro-chemical
process also means this value
will improve over the life of the
part, further optimizing circuit
efficiency
No derating up to 85 °C
• This enables designers to
achieve more capacitance per
specified and rated voltage
when used below 85 °C
• Solid tantalum equivalents
require up to 50 % derating
Withstand up to 3 V of reverse
voltage for wet tantalum
capacitors with a tantalum
metal case
• Solid tantalum or silver
tantalum cased parts can
exhibit catastrophic failure
due to reverse voltages
High temperature operation.
For example, 230 °C for the
T11 series
• Most wet tantalum families
are restricted to +125 °C
operation
High ripple currents. For
example, 2360 mA at 40 kHz
for the 10 V, 750 µF 135D
series
• This stops the device from
overheating and subsequently
failing during operation
• It means they significantly
outperform aluminum
electrolytic equivalents
No aging or reforming required
after prolonged storage
• They also have an unlimited
shelf life when stored in a
controlled environment
• Some devices have been
successfully used in avionics
and space applications for
over 50 years
1
4
2
5
3
6
