Pagina 1/24
EN
Quick guide
PRODUCT DESCRIPTION
1. Control panel
2. Fan
3. Shelf guides
(the level is indicated on the front of the
oven)
4. Door
5. Upper heating element/grill
6. Lamp
7. Identication plate
(do not remove)
8. Bottom heating element
(non-visible)
1
2
3
4
7
8
6
5
CONTROL PANEL
1 2 5 63 2 4
1. SELECTION KNOB
For switching the oven on by selecting a function. Turn to the position
to switch the oven o.
2. - / + BUTTONS
To decrease or increase the value shown on the display.
3. TIME BUTTON
For selecting the various settings: duration, cooking end time, timer.
4. DISPLAY
5. THERMOSTAT KNOB
Turn to select a desired temperature, activating the selected function.
6. LED THERMOSTAT / PREHEATING
Switches on during the heating process. Switches o once the desired
temperature is reached.
Please note: The knobs are retractable. Press the knobs in the middle and
they pop up.
ACCESSORIES
The number and type of accessories may vary depending on which model
is purchased. Other accessories that are not supplied can be purchased
separately from the After-sales Service.
WIRE SHELF. Use to cook food or as a support
for pans, cake tins and other ovenproof items
of cookware.
DRIP TRAY. Use as an oven tray for cooking
meat, sh, vegetables, focaccia, etc. or position
underneath the wire shelf to collect cooking
juices.
BAKING TRAY. Use for cooking all bread and
pastry products, but also for roasts, sh en
papillotte, etc.
Insert the wire shelf horizontally by sliding it across the shelf guides,
making sure that the side with the raised edge is facing upwards.
Other accessories, such as the drip tray and the baking tray, are
inserted horizontally in the same way as the wire shelf.
SLIDING RUNNERS.*
To facilitate inserting or removing accessories.
Remove the protective plastic o them. Place the drip
tray on the telescopic runners xing it between the
rear and front fastener.
The sliding runners can be tted on any level. To t the sliding runners,
fasten the upper clip of the runner to the shelf guide and slide it along as
far as it will go (1). Lower other clip into position. To secure the guide, press
the lower portion of the clip rmly against the shelf guide (2). Make sure
that the runners can move freely. Repeat these steps on the other shelf
guide on the same level.
1 2
REMOVING AND REFITTING THE SHELF GUIDES
To remove the shelf guides, lift the guides up and then gently pull the
lower part out of its seating: the shelf guides can now be removed.
To ret the shelf guides, rst t them back into their upper seating.
Keeping them held up, slide them into the cooking compartment, then
lower them into position in the lower seating.
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
* Available only on certain models
Probleemoplossing Whirlpool AKP 460/IX
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Ingebouwd |
| Soort bediening: | Draaiknop |
| Vermogen grill: | 2500 W |
| Kleur van het product: | Roestvrijstaal |
| Ingebouwd display: | Ja |
| Breedte: | 595 mm |
| Diepte: | 564 mm |
| Hoogte: | 595 mm |
| Netbelasting: | 2500 W |
| Grill: | Ja |
| Energie-efficiëntieklasse: | A-10% |
| Verlichting binnenin: | Ja |
| Geïntegreerde klok: | Ja |
| Soort klok: | Elektronisch |
| Convectie koken: | Ja |
| Aantal lampen: | 1 lampen |
| Totale binnen capaciteit (ovens): | 60 l |
| Aantal ovens: | 1 |
| Controle positie: | Voorkant |
| Installatie compartiment breedte: | 560 mm |
| Installatie compartiment diepte: | 550 mm |
| Installatie compartiment hoogte: | 600 mm |
| Stroom: | 16 A |
| Verwijderbare oven deur: | Ja |
| Energieverbruik (conventioneel): | 0.85 kWu |
| Energieverbruik (geforceerde convectie): | - kWu |
| Koken: | Ja |
| Grootte oven: | Middelmaat |
| Soort oven: | Elektrische oven |
| Totaal vermogen van de oven: | - W |
| Netto capaciteit oven: | 60 l |
| Boven- en onderverwarming: | Ja |
| Thermostaatbereik oven: | 50 - 250 °C |
| Koeldeur: | Ja |
| Type timer: | Digitaal |
| AC-ingangsspanning: | 230 V |
| AC-ingangsfrequentie: | 50 Hz |
| Type beeldscherm: | LED |
| Oven-ontdooifunctie: | Ja |
