Pagina 1/4
EN
Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
1. Control panel
2. Circular heating element
(non-visible)
3. Fan
4. Shelf guides
(the level is indicated on the front of
the oven)
5. Door
6. Upper heating element/grill
7. Lamp
8. Identication plate
(do not remove)
9. Bottom heating element
(non-visible)
5
4
3
2
1
5
4
3
2
1
2
1
3
4
5
8
9
7
6
CONTROL PANEL
1. SELECTION KNOB
For switching the oven on by selecting a function.
Turn to the position to switch the oven o.
2. TIMER KNOB
For setting the desired cooking time.
3. THERMOSTAT KNOB
Turn to select the desired temperature.
4. LED THERMOSTAT / PREHEATING
Switches on during the heating process.
Switches o once the desired temperature is reached.
Please note: The knobs are retractable. Press the knobs in the middle and
they pop up.
* Available only on certain models
ACCESSORIES
The number and type of accessories may vary depending on which model
is purchased. Other accessories that are not supplied can be purchased
separately from the After-sales Service.
WIRE SHELF. Use to cook food or as a support for pans,
cake tins and other ovenproof items of cookware.
DRIP TRAY. Use as an oven tray for cooking meat, sh,
vegetables, focaccia, etc. or position underneath the
wire shelf to collect cooking juices.
BAKING TRAY. Use for cooking all bread and pastry
products, but also for roasts, sh en papillotte, etc.
Insert the wire shelf horizontally by sliding it across the shelf guides,
making sure that the side with the raised edge is facing upwards. Other
accessories, such as the drip tray and the baking tray, are inserted
horizontally in the same way as the wire shelf.
SLIDING RUNNERS.*
These make it easier to place accessories in and
remove accessories from the oven.
To t the sliding runners, remove the shelf guides and take the protective
plastic o o them. Fasten the upper clip of the runner to the shelf guide
and slide it along as far as it will go (1). Lower other clip into position. To
secure the guide, press the lower portion of the clip rmly against the shelf
guide (2). Make sure that the runners can move freely. Repeat these steps
on the other shelf guide on the same level. The sliding runners can be
tted on any level. Reposition the shelf guides and rest the accessories on
them.
1 2
REMOVING AND REFITTING THE SHELF GUIDES
To remove the shelf guides, lift the guides up and then gently pull the
lower part out of its seating: the shelf guides can now be removed.
To ret the shelf guides, rst t them back into their upper seating.
Keeping them held up, slide them into the cooking compartment, then
lower them into position in the lower seating.
1 2 3 4
Probleemoplossing Whirlpool AKP9 780 IX
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Ingebouwd |
| Soort bediening: | Draaiknop |
| Vermogen grill: | 2500 W |
| Kleur van het product: | Roestvrijstaal |
| Deurscharnieren: | Neer |
| Ingebouwd display: | Nee |
| Gewicht: | 32000 g |
| Breedte: | 595 mm |
| Diepte: | 564 mm |
| Hoogte: | 595 mm |
| Netbelasting: | 2750 W |
| Grill: | Ja |
| Snoerlengte: | 0.9 m |
| Uitgestelde start timer: | Nee |
| Wi-Fi-besturing: | Nee |
| Energie-efficiëntieklasse: | A |
| Gewicht verpakking: | 34000 g |
| Breedte verpakking: | 630 mm |
| Diepte verpakking: | 650 mm |
| Hoogte verpakking: | 690 mm |
| Verlichting binnenin: | Ja |
| Convectie koken: | Ja |
| Aantal lampen: | 1 lampen |
| Soort lamp: | Halogeen |
| Totale binnen capaciteit (ovens): | 73 l |
| Aantal ovens: | 1 |
| Makkelijk schoon te maken: | Ja |
| Controle positie: | Voorkant |
| Installatie compartiment breedte: | 568 mm |
| Installatie compartiment diepte: | 550 mm |
| Installatie compartiment hoogte: | 585 mm |
| Soort reiniging: | Hydrolytisch |
| Stroom: | 13 A |
| Hoeveelheid glazendeur panelen: | 2 |
| Installatie compartiment hoogte (min): | 583 mm |
| Energieverbruik (conventioneel): | 0.91 kWu |
| Energieverbruik (geforceerde convectie): | 0.82 kWu |
| Energie-efficiëntie-index (EEI): | 95.3 |
| Koken: | Ja |
| Grootte oven: | Middelmaat |
| Soort oven: | Elektrische oven |
| Netto capaciteit oven: | 73 l |
| Zelfreinigend: | Ja |
| Indrukbare knoppen: | Ja |
| Type timer: | Mechanisch |
| Installatiecompartiment breedte (min): | 560 mm |
| Pizzafunctie: | Ja |
| Heteluchtgrillen: | Ja |
| Kerntemperatuurmeter: | Nee |
| Binnenmateriaal: | Emaille |
| Aantal kookprogramma's: | 8 |
| Reinigingstechnologie: | Hydrolytisch |
| Inclusief grilrooster: | Ja |
| Timermodi: | Einde kooktijd |
| Verhitting van gehele grilloppervlak: | Ja |
| AC-ingangsspanning: | 220 - 240 V |
| AC-ingangsfrequentie: | 50/60 Hz |
| Energie-efficiëntieschaal: | A+++ tot D |
| Oven-ontdooifunctie: | Ja |
| Diepvriesmodus: | Ja |
