Whirlpool FFT D 9X3SK EX Handleiding
Hier is de Whirlpool FFT D 9X3SK EX (Wasdroger) gebruikershandleiding. 12 pagina's in taal Universeel met een gewicht van 2,900,880.0 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/12
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.whirlpool.eu/docs and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product's identification plate.
EN
Before using the appliance carefully
read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
Quick guide
Before using the appliance carefully
read the Safety Instruction.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
NAVIGATION
The "UP" and "DOWN" buttons serve to navigate the available
menus.
• Press the button to confirm the selection.
• Press the option button at the symbol , where present on the
display, to return to the previous screen.
If no selection is conrmed, after about 10 seconds, the display
return to the main screen.
SETTINGS
To access the settings menu, keep the relevant button pressed for
some seconds.
• Set language shows the available languages on the display.
• Sounds allows to enable or disable the sounds (some sounds, as
warnings, will remain active anyway).
• Brightness allows to modify the display brightness.
• Factory Default allows to reset the default settings. After having
selected the setting, keep the button pressed for some
seconds.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your lters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door filter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items. For
optimal drying result, garments should be loaded one by one.
3. Close the door.
4. Press the "On/Off" button.
5. Select the most suitable programme
for the type of fabric in
that load.
6. Select the options, if necessary.
7. Press the "
Start/Pause"
button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Turn the machine
off by pressing the "On/Off" button, open the door and pull the
clothing immediately out to prevent the formation of creases on
laundry.
If the machine is not switched off manually, after about a quarter
of an hour from the end of the cycle , the appliance turns off
automatically to save energy.
Note that some models perform a final cool tumble phase, for this
reason the fabrics may not feel hot.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle.
Eco Monitor
This indicator shows the energy consumption level according to
the programme and the options set. The consumption is
proportional to the lines on the display,by the ecomonitor icon.
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
INDICATORS
Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry
Cycle phase: Drying - Cool down - End of cycle.
Empty water tank - Clean door lter - Clean bottom lter - Eco Monitor
Refer to troubleshooting section: Failure: Call after sales service
FIRST TIME USE
When starting the appliance for the first time, the control panel
will show the set language menu automatically. The UP and
DOWN buttons serve to show the languages available in the
machine. Press the button to confirm. The machine cannot
be used without having selected the language. Make sure that
the water tank is correctly inserted. Make sure that the drain
hose on the back of the dryer is fixed correctly, either to the
dryer’s water tank, or to your domestic sewage system.
The dryer must be installed in ambient with a temperature
range between 5-35 °C to ensure its operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
CONTROL PANEL
1 On/Off button
2 Start/Pause button
Options Buttons
3 Fresh Care +
4 Rapid (Add Favourite if long pressed)
5 Cycle Options (Setting if long pressed)
6 Dryness Level
7 Timed Drying
8 Start Delay
Navigation buttons and Key Lock
9 UP
10 DOWN'
11 CONFIRM (Key Lock if long pressed)
3
4
5
9
10
11
SYNTHETICS
1:35
-:--
-:--
6 7 8
1
2
