Pagina 1/4
EN
Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your appliance on
www.whirlpool.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more detailed
instructions on how to remove them, see the Installation Guide.
PROGRAMME CHART
1. “ON/OFF” button
2. Programme selector
3. “Temperature” button
60°
40°
4. “Spin” button
5. “Start delay” button
6. “Start/Pause” button
7. Option buttons
8. “Key lock“button
INDICATORS
Door can be opened
Washing phase
Indicates washing phase of the cycle
Failure: Call Service
Refer to Troubleshooting section
Failure: Water lter clogged
Water cannot be drained; water lter
might be blocked
Failure: Water tap closed
No or not sucient inlet water. “Beep”
sound every 5 seconds.
In the event of any failures, refer to the
Troubleshooting section in USER MANUAL
CONTROL PANEL
2.1. 6.3. 4. 5.
8.7. 7.
PRODUCT DESCRIPTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter - behind plinth
7. Plinth (removable)
8. Adjustable feet (4)
1.
2.
7.
3.
4.
5.
6.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover
or water softener. For a liquid detergent it is
recommended to use removable plastic partition
A (supplied) for a proper dosage. If powder
detergent is used, place the partition into slot B.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch.
Pour in softener or starch solution only up to the “max” mark.
Release button
Press to remove tray for cleaning.
AB
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of the
programmes, without options.
** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
*** The duration of the programme is shown on the display.
6th Sense - the sensor technology adapts water, energy and programme duration to your wash
load.
Eco Cotton - Test wash cycles in compliance with regulations 1061/2010
These are the reference programs for the energy label. Set this wash cycles with a
temperature of 40°C or 60°C. They are the most ecient programmes in terms of energy
and water consumption for washing normally soiled cotton laundry. The actual water
temperature may dier from the declared one.
For all Test Institutes:
Long wash cycle for cottons: set wash cycle with a temperature of 40°C.Cotton
Synthetic program along: set wash cycle Synthetics
with a temperature of 40°C.
Max load 8 Kg
Power consumption in o -mode 0.5 W / in left-on mode 8 W Detergents and additives Recommend-
ed detergent
Residual
dampness % (**)
Energy
consumption kWh
Total water lt
Programme
Temperatures Max.
spin
speed
(rpm
Max
load
(kg
Duration
(Minutes
Prewash Main
wash Softener Pow-
der Liquid
Default Range
Mixed 40°C - 40°C 4 –1000 *** – – – –
Whites 60°C - 90°C 81200 *** (90°) – – –
Cotton 40°C - 60°C 8 230 –1200 53 0,89 88
Eco Cotton 60°C 60°C 8 210 –1200 53 1,17 55
40°C 8 230 –1200 53 0,89 88
Bed linen 60°C - 60°C 8 –1200 *** – – –
Sport 40°C - 40°C 4 –600 *** – – – –
Duvets 30°C - 30°C 2 –1000 *** – – – –
Steam Refresh – – – 1.5 – – – – – – – –***
Spin+Drain – – 8 – – – – – – – –1200 ***
Rinse+Spin – – 8 – –1200 *** – – – – –
Rapid 30’ 30°C - 30°C 3 –800 *** – – – –
Colours 15° 15°C 15°C 4 – 1000 *** – – – –
Silk 30°C - 30°C 1 –– *** – – – –
Wool 40°C - 40°C 1.5 –800 *** – – – –
Delicates 30°C - 30°C 1 –– *** – – – –
Synthetics 40°C - 60°C 4 –1200 200 32 0,80 78
Dosing required Dosing optional
