ITA-5831 Startup Manual 1
The ITA-5831 series of compact fanless systems are
powered by a 6th generation Intel® Core™ i processor and
fully compliant with the EN 50155 standards for railway and
industrial applications. These powerful computing platforms
can withstand 24/7 operation under harsh conditions.
Before card installation, ensure that the following items
have been shipped:
1. 1 x ITA-5831 series IPC
2. 1 x ITA-5831 accessory box
3. 1 x ITA-5831 warranty card
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: FordetailedITA-5831specications,refertothe
Advantech website http://www.advantech.com.
Note 2: Acrobat Reader is required to view any PDF
le.AcrobatReadercanbedownloadedfrom
http://get.adobe.com/reader/ (Acrobat is a trade-
mark of Adobe)
ITA-5831 Series of Compact Fanless Systems with
6th Generation Intel® Core™ i Processor and
EN 50155 Certication for Railway Applications
Startup Manual
Standard Functions
• Chip and Chipset: Intel® Core™ i BGA1023 processor
with QM170, CPU frequency 2.8 GHz max.
• BIOS: AMISPI128MBash
• Memory: Onboard 8 GB/16 GB DDR4, 2133 MHz
• Display: Intel Integrated Graphics GT2
Up to 512 MB shared memory, supports Direct x11
• Display Mode:
- DVI: 1920x1200 @ 60 Hz
- VGA: 1920x1200 @ 60 Hz (optional)
• Storage: Supports 3 x 2.5” SSD (hot-pluggable, RAID
0,1,5,10), 1 x internal mSATA slot
• Expansion: 3 x Mini PCIe slots (2 with SIM slot)
SystemSpecications
• Ethernet: 3 x 10/100/1000M Ethernet, M12 x-coded,
8-pin, Female
• USB:
1 x USB 2.0, M12 A-coded, 4-pin, Female
2 x USB 3.0, Type A
• Display: 1 x DVI-I connector
• Serial Port:2xDB9withRS-232/422/485automaticow
control
• Digital I/O: 4 x DI and 4 x DO with 2kV isolation, DB9/
Female
• Audio: 1xAudioOut(supports2-ch4W4Ωspeaker),
1 x Line In, DB9/Female
Mechanical and Environmental
• Dimensions (W x H x D):
- 220 x 88 x 197.2 mm (8.66 x 3.46 x 7.76 in)
- 256 x 93.5 x 197.2 mm (10.0 x 3.68 x 7.76 in) with mount kit
• Input Voltage: Compliant with EN 50155/EN 50121-3-2
24V
DC
, 4.16A
48V
DC
, 3.18A
72V
DC
, 2.12A
110V
DC
, 1A
• Operating Temperature: -40 ~ 70 °C (-40 ~ 158 °F) with
wide-temperature SSD, EN50155 Tx level
• Safe Operating Temperature: 50 °C (122 °F) max.
• Storage Temperature: -40 ~ 85 °C (-40 ~ 185 °F)
• Weight: 4.5 kg (9.92 lb)
Specications Packing List
For more information about this or other Advantech
products, visit the Advantech website at
http://www.advantech.com
For technical support and customer service, visit the
Advantech support website at
http://support.advantech.com.tw
This manual is for the ITA-5831 series.
Part No. 2041583111
Printed in China
Edition 2
June 2021
