PCE-GIGE2/GIGE4 Startup Manual 1
Before you begin installing your card, please make sure
that the following items have been shipped:
1. 1 x PCE-GIGE2/GIGE4 GbE expansion card
2. 1 x CD with utility P/N: 2061GIGE00
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
General
• PCE-GIGE2-00A1E:
2 Ports GbE expansion card.(Each
Port is designed in a dedicated Ethernet controller and
will occupy one system I/O)
• PCE-GIGE4-00A1E:
4 Ports GbE expansion card.(Each
port is designed in a dedicated Ethernet controller and will
occupy one system I/O)
• Chipset:
4 Intel
®
i210 Ethernet Controllers
Compliant with Ethernet specification
• Interface:
PCI Express p1-x4 (Gen2.0)
• Data Transfer Rate:
10/100/1000 MB/s
Mechanical and Environmental
• Dimensions: (L x W):
118 x 111 mm (MB); 43.5 x 111 mm (Carry board)
• Power requirements:
Slot: PCI Express 2.0 standard
• Net Weight:
0.098 Kg (PCE-GIGE2) / 0.114 Kg (PCE-GIGE4)
PCE-GIGE2/GIGE4 GbE Expansion Card
Startup Manual
Main Board Connectors
Label Function
LAN1~4 LAN port 1~4
The drivers for the PCE-GIGE2/PCE-GIGE4 series are lo-
cated on the software installation CD. Please click through
the folder and follow the screen instructions to install them.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditons:
1. This device may not cause harmful interference;
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the PCE-GIGE2/GIGE4 Series Rev.
A1.
Part No. 2001GIGE00
Printed in China
1st Edition,
Aug 2017
Specications
Connectors
Software Installation
Declaration of Conformity
