PCE-5B10-04A1E Startup Manual 1
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 2 Two Port USB Cable P/N: 1700002204
• PCE-5B10-04A1E Start-up Manual
• M4*6*0.7 Round Screws (20 pieces) P/N: 1939000410
• 2 years quality warranty card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B10-04A1E Backplane: 10-slot BP for 14-Slot
Chassis, 1 PICMIG 1.3, 5 PCIe, 4 32-bit/33-MHz PCI
Startup Manual
Standard PC functions
PICMG 1.3 Slot:
PCE-5B10-04A1E supports PCE-5XXX CPU Cards
PCIe Slots:
1 PCI-E x 16 Slot
4 PCI-E x 1 Slots
32-bit PCI Slots:
4 32-Bit / 33-MHz PCI Slots
USB (2.0) support: Four Universal Serial Bus ports to
Backplane
Mechanical and Environment
Dimensions: 327.66 x 315.45 mm
Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
Power requirements: Depends on the CPU Board, ad-
don Card & Peripherals
Operating temperature: 0 ~ 60° C
•
•
•
•
•
•
•
•
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B10-04A1E series Rev.
A1
Part No. 200K5B1000
Printed in China
1st Edition,
Feb. 2008
