PPC-3211SW_3181SW_3151SW-P65A/324W-P7 Series Startup Manual 1
Before installation, ensure that the following items are
included with the product:
1. 1 x Panel PC
2. 1 x PPC-3211SW/3181SW/3151SW/324W-P7 startup
manual
3. 1 x Phoenix connector
4. 10/12/14 x Mount brackets (10 for PPC-3151SW; 12 for
PPC-3211SW/3181SW; and 14 for PPC-324W-P7)
5. 10/12/14 x Mount screws (10 for PPC-3151SW; 12 for
PPC-3211SW/3181SW; 14 for PPC-324W-P7)
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Software Installation
Before installing software on the panel PC, install the cor-
responding drivers to ensure full functionality.
All drivers can be downloaded from the Advantech website
at http://www.advantech.com.
PPC-3211SW/3181SW/3151SW/324W-P7
21.5”/18.5”/15.6”/23.8” Panel PC with TFT LCD
and 6th/7th Gen Intel
®
Core
TM
Processor
Startup Manual
Note: The examples provided in this manual are of the
PPC-3211SW model.
Front View
Rear View
A. 2 x LAN
B. 1 x HDMI
C. 2 x USB 3.0
D. 2 x USB 2.0
E. COM2: RS-232/422/485
F. COM1: RS-232
G. DC-In
H. Power button
VESA mount screws: 4 x M4 screws
Screw depth: 12 mm (max.)
Packing List
For more information about this product, visit the
Advantech website at
http://www.advantech.com/products/fanless-panel-
pcs/sub_1-2jkjm3
For technical support and customer service, visit the
Advantech support website at
http://support.advantech.com/support/new_de-
fault.aspx
This manual is for the PPC-3211SW/3181SW/3151SW
/324W-P7 series, Rev. A0, models.
Part No. 2043315101
Printed in China
Edition 2
October 2020
Appearance
I/O Layout
