AXVI-1785 AXVI-1785
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
AXVI-1785 AXVI-1785
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
AXVI-1785
Mercedes accessory and NAV output CAN Interface 2001-2004
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING THE AXVI-1785
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
WIRING THE AXVI-1785
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
WIRING THE AXVI-1785
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
WIRING THE AXVI-1785
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
AXVI-1785
Mercedes accessory and NAV output CAN Interface 2001-2004
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
AXVI-1785
Mercedes accessory and NAV output CAN Interface 2001-2004
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
MERCEDES
C Class 2001-2004
CLK Class 2004
CLK500 2003
CLK55AMG 2003
APPLICATIONS
AXVI-1785
Mercedes accessory and NAV output CAN Interface 2001-2004
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
MERCEDES
C Class 2001-2004
CLK Class 2004
CLK500 2003
CLK55AMG 2003
MERCEDES
C Class 2001-2004
CLK Class 2004
CLK500 2003
CLK55AMG 2003
MERCEDES
C Class 2001-2004
CLK Class 2004
CLK500 2003
CLK55AMG 2003
