BEFORE YOU BEGIN
Small Flat Panel Mounts
Model: F-Series
This Instruction Manual covers most of the F-Series wall
and desk mounts, as well as selected F-Series pole
mounts.
NOTE: Some F-Series mounts (e.g., Table, Pole) and F-
Series accessories have separate Instruction
Manuals.
See Specifications on page 3 for a complete list of
models covered by this Instruction Manual.
IMPORTANT ! : If an accessory such as an optional
laptop tray is being installed, complete all required
installation procedures within this document prior to
installing the accessory.
F-Series Mounts (Examples)
WARNING: It is the installer’s responsibility to make sure all components are properly assembled and installed
using the instructions provided. Failure to read, thoroughly understand, and follow all instructions can result in
serious personal injury, damage to equipment, or voiding of factory warranty.
• If you have any questions about this these instructions or your specific installation, contact Chief Manufacturing
at 1-800-582-6480 or 952-894-6280.
DISCLAIMER:
CSAV, Inc., and its affiliated corporations and subsidiaries (collectively, "CSAV"), intend to make this manual accurate and complete. However,
CSAV makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice
or obligation of any kind. CSAV makes no representation of warranty, expressed or implied, regarding the information contained herein. CSAV
assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document.
Probleemoplossing Chief FWS110B
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 254 mm |
| Diepte: | 55 mm |
| Hoogte: | 248 mm |
| Materiaal behuizing: | Metal, Plastic |
| Montagewijze: | Muur |
| Geschikt voor schermmaten: | 10 - 32 " |
| Maximale gewichtscapaciteit: | 18.1 kg |
| Horizontaal draaibaar: | 180 ° |
| Scharnier: | Ja |
| Montage interface compatibiliteit (min): | 75 x 75 mm |
| Montage interface compatibiliteit (max): | 100 x 100 mm |
| Bereik kantelhoek: | -15 - 15 ° |
