CoolerMaster MasterLiquid ML360 Sub-Zero Handleiding
Hier is de CoolerMaster MasterLiquid ML360 Sub-Zero (Niet gecategoriseerd) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 0.7 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
FEATURES
SPECIFICATIONS
PACKING INFORMATION
CHILLING PERFORMANCE
Cooler Master’s MasterLiquid ML360 SUB-ZERO is amongst
the first Thermoelectric Cooling (TEC) AIO liquid coolers
powered by Intel® Cryo Cooling Technology. Utilizing
revolutionary TEC technology in the water block coupled with
the redesigned 2nd Gen pump, no amount of heat can
contest the achievable cooling power of sub-ambient
temperatures.
With software co-developed with Intel® , the ML360 SUB-
ZERO makes multi-core overclocking effortless for maximum
performance even at extended durations. The 360mm
radiator paired with the enhanced pump dissipates any heat
rapidly without struggle.
2nd Generation Pump – Enhanced pump delivers higher
liquid flow for exceptional heat removal.
Thermoelectric Cooling – TEC sensors rapidly cool the
water block to combat heat even with the most intense
CPU overclocking.
Intel® Cryo Cooling Technology – Balanced
combination of hardware, software, and firmware
unleash maximum performance for gamers,
overclockers, and content creators.
Software Enabled – Simplified software easily fine-tunes
the TEC performance for a customized cooling solution.
360 mm Radiator – Enlarged surface area combined
with three SF120 fans eliminate heat quickly and
efficiently.
MASTERLIQUID ML360 SUB-ZERO
MLZ-D36M-A19PK- 12
Product Name
MasterLiquid
ML360 SUB ZERO
Product Number
MLZ
-D36M-A19PK- 12
Exterior Color
Black
CPU
Socket
Intel®
LGA
1200
Water Block Dimensions
89 x 79 x 86.7mm( 3.5 x 3.1 x 3.4 inch)
Radiator
Material
Aluminum
Dimensions
(L x W x H)
394 x 119.6 x 27.2mm(15.5 x 4.7 x 1.1
inch)
Pump
Dimensions
(L x W x H)
57.3 x 57.3 x 92.2mm( 2.3 x 2.3 x 3.6
inch)
MTTF (Hours)
198,000 hours
Noise Level (
dBA)
<35dBA
Connector
4
-Pin
Rated Voltage
(VDC)
12
Rated Current (A)
1.0A
Power
Consumption (W)
13.8W(Max)
Fan
Dimensions
(L x W x H)
120 x 120 x 25mm (4.7 x 4.7 x 1 inch)
Quantity (pcs)
3
LED Type
Non
-LED
Speed (RPM)
650~1900 RPM
±10%
Airflow (CFM)
59 CFM (Max)
Noise Level (
dBA)
8~26 dBA
Pressure
(mmH2O)
2.0
mmH₂O (Max)
Life Expectancy
(Hours)
160,000 hours
Power Connector
4
-Pin
Rated Voltage
(VDC)
12
Rated Current (A)
TDP (W)
250 W
RAM Clearance
N/A
Warranty
5 years
EAN code
4719512110225
UPC code
884102082535
Net weight
3.26
Gross weight
3.50
Carton dimension
(L x W x H)
49.5 x 46 x 37
Cont. W/ Pallet Carton/ Pallet W/O Pallet
20’ 720 20
40’ 1440 20
40 HQ 1728 24
Probleemoplossing CoolerMaster MasterLiquid ML360 Sub-Zero
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 3260 g |
| Gewicht verpakking: | 3500 g |
| Breedte verpakking: | 460 mm |
| Diepte verpakking: | 495 mm |
| Hoogte verpakking: | 370 mm |
| Soort: | Kit voor vloeistofkoeling |
| Geluidsniveau (lage snelheid): | 8 dB |
| Geluidsniveau (hoge snelheid: | 26 dB |
| Land van herkomst: | China |
| Maximum luchtstroom: | 59 cfm |
| Aantal ventilatoren: | 3 ventilator(en) |
| Thermal Design Power (TDP): | 250 W |
| Rotatiesnelheid ( max): | 1900 RPM |
| Rotatiesnelheid ( min): | 650 RPM |
| Verlichtings-led: | Nee |
| Geschikte locatie: | Processor |
| Ventilator diameter: | 120 mm |
| Fan voltage: | 12 V |
| Supported processor sockets: | LGA 1200 (Socket H5) |
| Maximum luchtdruk: | 2 mmH2O |
| Pulsbreedtemodulatie-ondersteuning: | Ja |
| Maten ventilator (b x d x h): | 120 x 25 x 120 mm |
| Fan connector: | 4-pin |
| Radiator materiaal: | Aluminium |
| Geluidsniveau pomp: | 35 dB |
| Pomp voltage: | 12 V |
| Pomp stroom: | 1000 mA |
| Stroomverbruik pomp: | 13.8 W |
| Radiator breedte: | 119.6 mm |
| Radiator diepte: | 394 mm |
| Radiator hoogte: | 27.2 mm |
| Breedte waterblok: | 79 mm |
| Diepte waterblok: | 89 mm |
| Hoogte waterblok: | 86.7 mm |
| Pompconnector: | 4-pin |
| Pomp gemiddelde storingsinterval (MTTF): | 198000 uur |
| Pompbreedte: | 57.3 mm |
| Pompdiepte: | 57.3 mm |
| Pomphoogte: | 92.2 mm |
