DO GUIDE
DM-TX-4KZ-202-C/DM-TX-4KZ-302-C
DigitalMedia 8G+® 4K60 4:4:4 HDR Transmitters
DO Connect the Device
Connect the device as required for the application.
Connections, Left Side (DM-TX-4KZ-302-C Shown)
Connections, Right Side
DO Install the Device
The Crestron® DM-TX-4KZ-202-C and DM-TX-4KZ-302-C can be mounted onto a at surface or onto
a rack rail.
Mounting onto a Flat Surface
Using four mounting screws (not included), mount the device onto a at surface such as a wall or a
ceiling.
Mounting onto a Wall
Mounting onto a Rack Rail
The DM-TX-4KZ-202-C and DM-TX-4KZ-302-C mount onto the front or rear rail of a rack. Position
either the left or right mounting ange of the device so that the holes align with the holes in the rack.
Then, secure the device to the rack using two rack mounting screws (not included).
Mounting onto a Rack Rail
DO Check the Box
QTY PRODUCT PART NUM.
1 Connector, 2-Pin 2003574
1 Connector, 5-Pin 2003577
1 Power Pack, 24 Vdc 1.25 A, 100-240 Vac 2045870
HDMI IN 1–2:
From HDMI®
audio/video
sources
DM OUT:
To DM® switcher,
receiver, or other
DM device or to
HDBaseT® device
24 V
1.0 A:
From included
power pack
HDMI OUT:
To HDMI
display
DISPLAY
PORT IN:
DisplayPort digital
video/audio input*
*DISPLAY PORT IN is available on the DM-TX-4KZ-302-C only.
COMPUTER:
To computer
or other USB
HID compliant
host
IR:
To IR
controllable
device
LAN:
10BASE-T/
100BASE-TX
Ethernet to
local network
device
COM:
To
RS-232
device
USB HID:
To mouse/
keyboard or
other USB HID
compliant device
Ground
