SAROS SB-200-P
Saros® Sound Bar 200, Powered
crestron.com | 800.237.2041
>High-quality, full-range amplified
stereo sound bar
>Delivers enhanced sound quality
and performance for use with any
flat panel display
>Mounts to a wall or sits on a shelf
>Balanced or unbalanced stereo
line-level audio input [1]
>Unbalanced stereo audio cable included
>Powers on and off automatically
>100 to 240 Volt AC powered
The Saros® SB-200-P is a stereo sound bar designed to provide
enhanced audio performance for a flat panel display. Its full-range, front-
firing speakers offer an improvement over the small, rear-facing speakers
typical of many display devices. The bracket included with the sound bar
allows for attachment to a wall surface, or the unit can be placed on a
shelf below or above the display.
Built-in amplification allows for direct connection to the line-level audio
output of the display device, or to the output of an audio preamp, switcher,
mixer, tv tuner, codec, or Crestron DM® receiver.[1] The amplifier powers on
automatically when an audio input signal is detected, and powers off if no
signal is detected for several minutes.
The SAROS SB-200-P sound bar is ideally suited for use with the
Crestron RL® 2 Group Collaboration System and other unified
communication and videoconferencing systems. It is equally well-suited
for use in any small to medium sized room or public space in a hotel,
restaurant, museum, medical center, airport, office building, or residence.
SPECIFICATIONS
Features & Performance
Woofers: (2) 3 inch (76 mm) polypropylene cone w/rubber surround
Passive Radiator: (2) 3 x 4-3/8 inch (76 x 112 mm) polypropylene cone
w/rubber surround
Tweeters: (2) 1 inch (25 mm) polyester dome
Amplifier Power: 20 Watts per channel, stereo
Frequency Response: 100 Hz to 20 kHz (±3 dB)
Output Sensitivity: 83 dB SPL @ 1 meter, both channels driven @ 1 Watt
Input Sensitivity: 0.75 Vrms per channel for full rated output
Go To Sleep Time: 20 minutes (±5 minutes) with no signal present
Wake Threshold: 5 mV (±2 mV) typical
Connections
BALANCED AUDIO INPUTS: (1) 5-pin 3.5 mm detachable terminal block;
Balanced stereo line-level audio input
[1];
Maximum Input Level: 0.85 Vrms;
Input Impedance: 10k Ohms
UNBALANCED AUDIO INPUTS: (2) RCA connectors, female;
Unbalanced stereo line-level audio input
[1];
Maximum Input Level: 0.85 Vrms;
Input Impedance: 10k Ohms;
NOTE: Right-angle plugs may be required for wall mount applications. A
59 inch (150 cm) right-angle RCA to straight RCA stereo cable is included.
100-240V~50/60Hz 50W: (1) IEC 60320 C8 main power inlet;
Mates with removable power cord, included
Controls & Indicators
100-240V~50/60Hz 50W: (1) Rocker switch, turns main power on or off
PWR: (1) Blue LED, indicates the main power switch is turned on
Power Requirements
Main Power: 50 Watts (500 mA maximum) @ 100-240 Volts AC, 50/60 Hz
Environmental
Temperature: 41° to 104° F (5° to 40° C)
Humidity: 10% to 90% RH (non-condensing)
Probleemoplossing Crestron Saros Sound Bar 200
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 1031 mm |
| Diepte: | 71 mm |
| Hoogte: | 106 mm |
| Bluetooth: | Nee |
| Connectiviteitstechnologie: | Bedraad |
| Audio-ingang (L, R): | 1 |
| Gemiddeld vermogen: | - W |
| FM-radio: | Nee |
| Audio-uitgangskanalen: | - kanalen |
| Ophangsysteem voor aan de muur: | Nee |
| Soundbar speaker RMS vermogen: | 20 W |
| Meegeleverde subwoofer: | Nee |
| Apple docking-compatibiliteit: | Niet ondersteund |
| Dockingconnector soort: | Niet ondersteund |
| Soundbar gewicht: | 3600 g |
| Diameter woofer: | 3 " |
| Aantal woofer drivers: | 2 |
| Diameter hogetonenluidspreker: | 1 " |
| Aantal tweeter drivers: | 2 |
| AC-ingangsspanning: | 100-240 V |
| AC-ingangsfrequentie: | 50 - 60 Hz |
| Stroomverbruik (typisch): | 50 W |
| Frequentiebereik centerluidspreker: | 100 - 20000 Hz |
