PRECAUTIONS
RWARNING! NEVER
connect the transceiver to an AC
outlet. This may pose a re hazard or result in an electric shock.
RWARNING! NEVER connect the transceiver to a power
source of more than 16 V DC such as a 24 V battery. This
could cause a re or damage the transceiver.
RWARNING! NEVER cut the DC power cable between
the DC plug and fuse holder. If an incorrect connection is
made after cutting, the transceiver might be damaged.
RWARNING! NEVER place the transceiver where normal
operation of the vehicle may be hindered or where it could
cause bodily injury.
RWARNING! NEVER operate the transceiver during a
lightning storm. It may result in an electric shock, cause
a re or damage the transceiver. Always disconnect the
power source and antenna before a storm.
CAUTION: DO NOT allow children to touch the
transceiver. Place the transceiver in a secure place to
avoid inadvertent use by unauthorized persons.
CAUTION: DO NOT expose the transceiver to rain, snow
or any liquids.
CAUTION: DO NOT use the non-specied microphone.
Other microphones have different pin assignments and
may damage the transceiver.
CAUTION: DO NOT use or place the transceiver in areas
with temperatures below –25°C or above +55°C, or in
areas subject to direct sunlight, such as the dashboard.
CAUTION: DO NOT operate the transceiver without
running the vehicle’s engine. The vehicle’s battery will
quickly run out when the transceiver transmits while the
vehicle’s engine is OFF.
CAUTION: DO NOT place the transceiver in excessively
dusty environments.
CAUTION: DO NOT place the transceiver against walls.
This will obstruct heat dissipation.
CAUTION: DO NOT use harsh solvents such as benzine
or alcohol when cleaning, as they will damage the
transceiver surfaces.
NEVER place the transceiver in an insecure place to avoid
inadvertent use by unauthorized persons.
BE CAREFUL! The transceiver will become hot when
operating continuously for long periods of time.
Icom is not responsible for the destruction, damage to, or
performance of any Icom or non-Icom equipment, if the
malfunction is because of:
• Force majeure, including, but not limited to, res,
earthquakes, storms, oods, lightning, other natural
disasters, disturbances, riots, war, or radioactive
contamination.
•The use of Icom transceivers with any equipment that is
not manufactured or approved by Icom.
VOICE CODING TECHNOLOGY
The AMBE+2™ voice coding Technology embodied in this
product is protected by intellectual property rights including
patent rights, copyrights and trade secrets of Digital Voice
Systems, Inc. This voice coding Technology is licensed
solely for use within this Communications Equipment.
The user of this Technology is explicitly prohibited from
attempting to extract, remove, decompile, reverse
engineer, or disassemble the Object Code, or in any other
way convert the Object Code into a human-readable form.
U.S. Patent Nos.
#8,595,002, #8,359,197, #8,315,860, #8,200,497,
#7,970,606, #6,912,495 B2.
Icom, Icom Inc. and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia, Australia,
New Zealand, and/or other countries.
dPMR and the dPMR logo are trademarks of the dPMR
MoU Association.
AMBE+2 is a trademark and property of Digital Voice
Systems Inc.
All other products or brands are registered trademarks or
trademarks of their respective holders.
EXPLICIT DEFINITIONS
WORD DEFINITION
RWARNING!
Personal injury, re hazard or electric
shock may occur.
CAUTION Equipment damage may occur.
NOTE
If disregarded, inconvenience only. No
risk of personal injury, re or electric
shock.
IMPORTANT
This instruction sheet includes some functions that are
usable only when they are preset by your dealer. The
transceiver may have other functions and operations that
are not described in this instruction sheet. Ask your dealer
for preset function details.
SUPPLIED ACCESSORIES
Microphone
Microphone hanger
and screw set
Microphone
hanger cable
DC power cable Function name
stickers*
Mounting bracket
Flat washers
Nuts Mounting screws
(5×12)
Bracket bolts Self-tapping screws
(5×20)
Spring washers
* Used for labeling the programmable function keys
according to their assigned functions.
NOTE: Some accessories are not supplied, or the shape
is different, depending on the transceiver version.
OPTIONS
•OPC-1939, OPC-2078 ACC CABLE
Enables you to connect to an external terminal.
OPC-1939: D-sub 15-pin, an external level converter
(user supplied) is required.
OPC-2078: D-sub 25-pin, built-in level converter
NOTE:
No Digital Modulation “IN” using accessory cables.
•HM-152, HM-152T, HM-148G, HM-148T, HM-211
HAND MICROPHONE
HM-152: Hand microphone
HM-152T:DTMF microphone
HM-148G: Self ground heavy duty microphone
HM-148T: Self ground heavy duty DTMF microphone
HM-211: Noise Canceling microphone
• SM-26 DESKTOP MICROPHONE
• SP-30, SP-35, SP-35L EXTERNAL SPEAKER
Input impedance: 4 Ω
SP-30: Rated input: 20 W, Maximum input: 30 W
SP-35, SP-35L: Rated input: 5 W, Maximum input: 7 W
ABOUT CE AND DOC
Hereby, Icom Inc. declares that the versions
of IC-F5122D and IC-F6122D which have
the “CE” symbol on the product, comply with
the essential requirements of the Radio
Equipment Directive, 2014/53/EU, and the
restriction of the use of certain hazardous substances in
electrical and electronic equipment Directive, 2011/65/EU.
The full text of the EU declaration of conformity is available
at the following Internet address:
https://www.icomjapan.com/support/
DISPOSAL
The crossed-out wheeled-bin symbol on your
product, literature, or packaging reminds you
that in the European Union, all electrical and
electronic products, batteries, and
accumulators (rechargeable batteries) must
be taken to designated collection locations at
the end of their working life. Do not dispose
of these products as unsorted municipal waste. Dispose of
them according to the laws in your area.
ANTENNA
A key element in the performance of any communication
systems is the antenna. Contact your dealer for
information regarding antennas and how to install them.
FUSE REPLACEMENT
Fuses are installed in the supplied DC power cable. If a
fuse blows, track down the source of the problem, repair it,
and then replace the damaged fuse with a new rated one.
LFuse rating: 250 V 10 A
NOTE: Use only specied fuses.
CLEANING
If the transceiver becomes dusty or dirty, wipe it clean with
a soft, dry cloth.
About E-marking: Detailed installation notes for
Icom mobile transceivers to be tted into vehicles are
available. Please contact your Icom dealer or distributor.
Fuse Coding explanation
Fuse Coding: FUSE 250 V 10 A
Fuse Voltage rating: 250 Volts
Fuse Current rating: 10 Amperes
For European versions
CAUTION: DO NOT Hot surfaces. touch
the transceiver’s surface after continuously
transmitting for long periods of time. The
transceiver’s chassis radiates heat, and it
will become hot to protect the power
amplier unit from overheating. Touching it
may cause a burn.
FREQUENCY RANGE AND OUTPUT POWER
Model Version
Frequency
Range
Output
Power
VHF Mobile Transceiver
IC-F5122D
EUR-31
DPM-31
136–174 MHz 25 W
UHF Mobile Transceiver
IC-F6122D
EUR-31
DPM-31
400–470 MHz
25 W
•
Channel spacing:
6.25 kHz*,
12.5 kHz, 20 kHz, 25 kHz
* Only Digital mode
1-1-32 Kamiminami, Hirano-ku,
Osaka 547-0003, Japan
Oct. 2021
A6906W-1EU-6
Printed in Japan
© 2011–2021 Icom Inc.
INSTRUCTIONS
Thank you for choosing this Icom product.
READ ALL INSTRUCTIONS carefully and completely
before using this product.
VHF MOBILE TRANSCEIVER
|F5122D
UHF MOBILE TRANSCEIVER
|F6122D
