Pagina 1/7
– – 1
Thank you for choosing this Icom product. READ
ALL INSTRUCTIONS carefully and completely
before using this product.
INSTRUCTION MANUAL
PROGRAMMING SOFTWARE
CS-IP110H
The CS-IP110H is an application software to setup the IP110H from your PC.
To use the software, a computer system and some items described in “System requirements” are required.
LThe instructions are based on using Microsoft Windows 10.
•Operating System (OS)
Microsoft Windows
11 (64bit)
Microsoft Windows 10 (32/64bit)
LExcept for Windows on ARM.
•USB port
A USB 1.1, 2.0, or 3.0 port
LIcom is not responsible for problems using a PC with
an OS other than one of the above installed.
•Cables
The USB cable supplied with the transceiver
or
OPC-478UC or OPC-478UC-1 programming cable
+ OPC-1655 programming adapter cable
System requirements (As of September 2024)
NOTE for the OPC-478UC :programming cable
•The OPC-478UC is not usable with Windows 11.
•Conrm your OPC-478UC has a “B” on its
label. Only the cables with a “B” are usable with
Windows 10.
Operation notes
•The contents of this sheet, the software associated
with the CS-IP110H, and the appearance of the
CS-IP110H are all subject to change without notice.
•The displays, indications, or operations may differ
slightly, depending on your system settings, type of
OS, and its service pack level.
Procedure outline
To setup from a PC, rst follow the steps described below.
Step 1 Preparations
Conrm the system requirements in these instructions.
Step 2 CS-IP110H installation
Install the CS-IP110H following these instructions.
Step 3 USB driver installation
Install the USB driver following these instructions and the optional programming cable’s installation guide.
Step 4 Connection
Connect the transceiver and a PC following these instructions, and then turn ON the transceiver.
