P40000 SERIES

POOL/SPA EQUIPMENT CONTROLS

INSTALLATION

OPERATION &

SERVICE MANUAL

CONTROL PANEL FOR INDOOR/OUTDOOR USE

Suitable for Pool Equipment Control and for Direct Connection of Underwater Lights

ELECTRICAL RATINGS: See inside Enclosure Door

Intermatic Pool and Spa load centers are

complete in construction and shall be installed

in accordance with NEC requirements as

applicable. These enclosures are provided

with provisions for single-gang certified

switching devices and an extra low voltage

transformer certified for use with underwater

pool lights with a breaker base. Enclosures

with breaker bases are certified as industrial

controls for specific use.

The Transformers supplied in these panels

are specifically designed to supply 12 volts

to underwater pool/spa lights. A grounded

shield between the primary and secondary

winding assures safe operation and the built-

in circuit protection will disconnect power to

the transformer in case of overload. These

transformers are suitable for direct connection

to underwater Pool and Spa lights.

The all-weather enclosure contains provisions

to install a switch inside as well as a switch or

GFCI receptacle on the outside.

GENERAL INFORMATION

Transformer Input Secondary Output

Rating

60 Hz.

Lamp Watts* Volts

100W 120V. 1 Amp Max. 100 Max. 12, 13 or 14

300W 120V. 3 Amp Max. 300 Max. 12, 13 or 14

* Any combination of bulbs, any tap.

Risk of electric shock!

Test ground fault protection regularly. If it fails, do not use Pool or Spa. Contact

qualified service professional for help.

Do not use this control as a power disconnect, it could turn ON unexpectedly.

Disconnect electricity at the main Panel before servicing this control or the

equipment(s) connected to it.

WARNING
