ACC3- -12 SP Quick Start
P/N:
2 9 0 0 - 3 0 1 6 8 1 QS
Rev:
2
Scan for full manual
ACC3- - Quick Start Guide 12 SP
This guide helps you install and use your ACC3- -12 SP for the rst time.
Go to www.kramerav.com/downloads/ACC3- -12 SP to download the latest user manual and check if
rmware upgrades are available.
Step 1: Check in the bwhat’s ox
ACC3- -12 SP 1:2 CAT Cable Splitter
1 Bracket set
4 Rubber feet
1 Quick start guide
Step 2: Get to know your ACC3- - 12 SP
#
Feature
Function
1
CAT A+B -45 Port RJ
Connect to a compatible CAT transmitter (for example an ) to send SWT3- -U-T41
combined signals over the A+B port.
Make sure the Dual CAT extension is set to active via CAT transmitter
embedded webpages.
2
CAT A RJ-45 Port
Connect to a compatible CAT receiver (for example an EXT3- -RUE , EXT3-U-R).
3
CAT B RJ-45 Port
Connect to a compatible CAT receiver (for example an EXT3- -RUE , EXT3-U-R).
Step 3: Mount ACC3- - 12 SP
Install using one of the following methods: ACC3- -12 SP
• Attach the rubber feet and place the unit on a at surface.
• Fasten a bracket (included) on each side of the unit and attach it to a at surface
(see www.kramerav.com/downloads/ACC3- -12 SP).
• Mount the unit in a rack using the recommended rack adapter
(see www.kramerav.com/product/ACC3- -12 SP).
• Ensure that the environment (e.g., maximum ambient temperature &
air ow) is compatible for the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be
used for avoiding overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
