Product Specication
© 2023 Microchip Technology Inc. and its subsidiaries
DS30010227C - 1
Product Overview
The WebStaX turnkey software package is a fully managed L2 switch application for the small and medium-sized
enterprise (SME). This software package can be customized to support dierent congurations. port It is built
on Linux to ensure cost optimization without compromising eciency. WebStaX supports the following major
capabilities.
• RedBoot bootloader
• U-boot bootloader
• Web or XMODEM update
Management is done using a web graphical user interface (GUI), command line interface (CLI), JavaScript Object
Notation-Remote Procedure Call (JSON-RPC), or Simple Network Management Protocol (SNMP) running on the
internal MIPS24Kec CPU. WebStaX is highly integrated with switch features such as QoS control lists (QCLs),
access control lists (ACLs), and super priority management queue.
This document provides an overview of the switch and software features of the WebStaX software and lays the
basis for further The supported details including parameters and limitations arespecications. conguration
beyond the scope of this document. The module requirement and guidesspecic specications conguration
may be referred to for obtaining these details.
Supported Switch Plaorms
This software is supported on a series of Microchip switches with 12, 26, or 57 ports with Power over Ethernet
(PoE)/non-PoE capabilities. The following table shows the supported switches.
Table 1. Supported Switches
Switch Description
VSC7410 6-port SGMII Gigabit Ethernet Switch with VeriTime™ and Gigabit Ethernet PHYs
VSC7414 11-port layer 2 SGMII Gigabit Ethernet Enterprise Switch with VeriTime™
VSC7415 6-Port SGMII Gigabit Ethernet Switch with VeriTime™, Integrated DPLL, and Gigabit Ethernet PHYs
VSC7416 6-port Carrier Ethernet Switch Engine with ViSAA™, VeriTime™, and MPLS/MPLS-TP
VSC7418 11-port Carrier Ethernet Switch Engine with ViSAA™
, VeriTime™, and MPLS/MPLS-TP
VSC7423 7-port, layer 2 Gigabit Ethernet Switch with VeriTime™, 5 Integrated Copper PHYs, and Embedded 32-bit CPU
VSC7424 10-port layer 2 Gigabit Ethernet Switch with 8 Fully Integrated Copper PHYs and Embedded 416-MHz CPU
VSC7425 18-port layer 2 Gigabit Ethernet Switch with 12 Fully Integrated Copper PHYs and Embedded 416-MHz CPU
VSC7426 24-port layer 2 Gigabit Ethernet Switch with 12 Fully Integrated Copper PHYs and Embedded 416-MHz CPU
VSC7427 26-port layer 2 Gigabit Ethernet Switch with 12 Fully Integrated Copper PHYs and Embedded 416-MHz CPU
VSC7428 11-port Carrier Ethernet Switch Engine with ViSAA™
, VeriTime™, and PHYs
VSC7429 26-port Carrier Ethernet Switch with ViSAA™, VeriTime™, and 12 Fully Integrated Copper PHYs
VSC7430 6-port Carrier Ethernet Switch with ViSAA™, VeriTime™, and Gigabit Ethernet PHYs
VSC7435 6-port Carrier Ethernet Switch with ViSAA™, VeriTime™, and Integrated DPLLs and Gigabit Ethernet PHYs
WebStaX Soware Product Specicaon
VSC6819
