Smart-AVI VCT-400 Handleiding
Hier is de Smart-AVI VCT-400 (AV extender) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 617,019.0 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
© Copyright 2010 Smart-AVI, All Rights Reserved
Notice
The information contained in this document is
subject to change without notice. Smart-AVI makes no
warranty of any kind with regard to this material, including
but not limited to, implied warranties of merchantability
and tness for any particular purpose.
Smart-AVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced or translated into another language with
out prior written consent from Smart-AVI.
For the complete manual, visit www.smartavi.com.
Use a single CAT5 to broadcast high
resolution UXGA to 4 locations
1000ft away
VCT400
www.smartavi.com
User Manual
2840 N. Naomi Ave.,
Burbank, California 91504
Phone: (818) 565-0011
Facsimile: (818) 565-0020
Technical Specications
Transmitter and receiver
Video
Bandwidth 400MHz
Analog signal Level 1 volt
Impedance 75 ohms
Connector High density HD15
Format VGA/SVGA/XGA/UXGA/RGBH/RGsB
Sync
TTL horizontal SyncRange: 15 to 130 KHz Verti-
cal Sync Range 30 to 120 Hz
Signal level OdB
Impedance 10K ohms
Connector 3.5mm jack socket
System Cable
Type Cat5 UTP EIA 568A
Connector RJ45
Power
Requirements 5V DC @500mA
Connector 5x2.1 DC Jack
