Use a single CAT5 to broadcast
high resolution UXGA and RS232
1000ft away
VDX
www.smartavi.com
User Manual
3111 Winona Ave., Suite 101
Burbank, California 91504
Phone: (818) 565-0011
Facsimile: (818) 565-0020
Technical Specifications
VDX SPECIFICATIONS
Video
Bandwidth 400 MHz
Analog Signal Level 1 Volt
Impedance 75 ohms
Connector High Density HD15
Format
VGA/SVGA/XGA/UXGA/
RGBH/RGBsB
Sync
TTL horizontal SyncRange:
15 to 130 KHz Vertical Sync
Range 30 to 120 Hz
RS232
Connection
Bi-directional Transmit Receive
Only, RXD, TXD
System Cable
Type CAT5 UTP EIA 568A
Connector RJ45
Power
Requirements 5V DC @1A
Connector 5x2.1mm DC jack
Weight
.5 lb (0.3 Kg)
ORDER INFORMATION
Model Description
VDX
Extends Video and RS232 up to
1000ft using cat5
