Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 22, 2022 1:50 PM
(Side A)
(Side B)
Product Diagram
Component Function
1Built-in USB-C Host Cable
• Connect to a USB-C Port on a Host Computer
• USB 3.2 Gen 1 (5 Gbps)
• Power Delivery 3.0 Specication
2USB-C 100W Power
Delivery Port
• Connect a USB-C power adapter
• USB Power Delivery 3.0 (up to 100W, with up to
86W available for charging)
3HDMI Output Port
• Connect to an HDMI Display Device
• HDMI 2.0
• Up to 4K (4096x2160) 60Hz
• Via DisplayPort 1.4 DP Alt Mode
42x USB-A Data Ports
• Connect USB-A Peripherals
• USB 2.0 (480 Mbps)
• Supports up to 5 V/0.5 A (2.5 W) of Power
5USB-A Data Port
• Connect USB-A Peripherals
• USB 3.2 Gen 1 (5 Gbps)
• Supports up to 5 V/0.9 A (4.5 W) of Power
Product ID
104B-USBC-MULTIPORT
USB-C Multiport Adapter - Works With Chromebook - HDMI 4K 60Hz HBR3 - 1 x USB-A (5Gbps) - 2 x USB 2.0 - 100W PD - Extended Cable
4
1
4
32
Requirements
• Computer
• DP Alt Mode enabled USB-C Port
• Video performance, such as resolution, and refresh rate depends upon your
host computer’s video controller. Please verify the specications of your
computer.
For the latest drivers, manuals, product information, technical specications, and
declarations of conformance, please visit: www.StarTech.com/104B-USBC-MULTIPORT
Package Contents
• USB-C Multiport Adapter x 1
• Quick-Start Guide x 1
Installation
1. Connect the , located on the Multiport Adapter to a Built-in USB-C Host Cable
USB-C port on your host computer. Your computer will automatically detect the
device and install all the required drivers.
2. ( Optional) Connect a USB-C power adapter (up to 100W) from an AC outlet to the
USB-C 100W Power Delivery Port located the Multiport Adapter, to charge the
host computer that’s connected to .Built-in USB-C Host Cable
3. Connect an HDMI Enabled Display Device, to the , located on HDMI Output Port
the Multiport Adapter, using an HDMI cable.
4. Connect USB Peripheral Devices to the , located on the USB-A Data Ports
Multiport Adapter.
Note: High powered USB devices, such as bus powered SSD enclosures, are not
recommended for use with the , located on this device.USB-A Data Ports
This product works with devices capable of running the latest version of Chrome
OS and has been certied to meet Google’s compatibility standards. Google is not
responsible for the operation of this product or it’s compliance with safety requirements.
Chromebook and the Works With Chromebook badge are trademarks of Google LLC.
Ce produit est compatible avec les appareils en mesure d’exécuter la dernière
version de Chrome OS et a été certié conforme aux normes de compatibilité de Google.
Chromebook et
le badge Works With Chromebook sont des marques de commerce de Google LLC.
5
Probleemoplossing StarTech.com 104B-USBC-MULTIPORT
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart, zilver |
| Gewicht: | 105 g |
| Breedte: | 48 mm |
| Diepte: | 100 mm |
| Hoogte: | 16 mm |
| Gewicht verpakking: | 120 g |
| Breedte verpakking: | 115 mm |
| Diepte verpakking: | 180 mm |
| Hoogte verpakking: | 40 mm |
| Materiaal behuizing: | Kunststof |
| Ondersteunde mobiele besturingssystemen: | Android |
| Connectiviteitstechnologie: | Bedraad |
| Ethernet LAN: | Nee |
| Geïntegreerde geheugenkaartlezer: | Nee |
| Snelstartgids: | Ja |
| Aantal USB 2.0-poorten: | 2 |
| Aantal HDMI-poorten: | 1 |
| Microfoon, line-in ingang: | Nee |
| HDR-ondersteuning: | Ja |
| HD type: | 4K Ultra HD |
| HDMI versie: | 2.0b |
| Resolutie (maximum digitaal): | 4096 x 2160 Pixels |
| Duurzaamheidscertificaten: | RoHS |
| Temperatuur bij opslag: | -25 - 65 °C |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 1 |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C: | 1 |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ubuntu 18.04 LTS, Ubuntu 20.04 LTS |
| Hostinterface: | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Andere ondersteundende systemen: | ChromeOS |
| USB Power Delivery: | Ja |
| USB Power Delivery herziening: | 3.0 |
| USB Power Delivery tot max.: | 100 W |
| USB Type-C DisplayPort alternatieve modus: | Ja |
| Chipset: | Analogix - ANX7327, Analogix - ANX7518, VIA - VL817-Q7 |
| USB kabel lengte: | 0.35 m |
| (Buitenste) hoofdverpakking hoogte: | 230 mm |
| (Buitenste) hoofdverpakking breedte: | 230 mm |
| (Buitenste) hoofdverpakking lengte: | 368 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 20 stuk(s) |
| Overdrachtssnelheid: | 5 Gbit/s |
| Stroomverbruik (typisch): | 14 W |
| Bedrijfstemperatuur (T-T): | 0 - 45 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| High Dynamic Range 10 (HDR10): | Ja |
