Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 04/19/2017
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/USB31C2SAT3.
Package contents
• 1 x adapter cable
• 1 x universal power adapter (NA/JP, UK, EU, ANZ)
• 1 x quick-start guide
Requirements
• USB-enabled computer system with an available USB-C port
The USB31C2SAT3 is OS independent and doesn’t require any
additional drivers or software.
Note: To obtain the maximum USB throughput, you must use a
system with a USB 3.1 Gen 2 (10Gbps) port.
Requirements are subject to change. For the latest requirements,
please visit www.StarTech.com/USB31C2SAT3.
USB31C2SAT3
USB 3.1 (10Gbps) Adapter Cable for 2.5/3.5” SATA Drives - USB-C
*actual product may vary from photos
Product diagram
Connect the adapter
Warning! Drives should be handled carefully, especially when they’re
transported. If you’re not careful with your drive, you may lose data
as a result. Make sure that you’re properly grounded by wearing an
anti-static strap when you install any computer component. If an
anti-static strap isn’t available, touch a large, grounded metal surface
for several seconds to discharge any built-up static electricity.
1. Connect a 2.5” or 3.5” SATA SSD or HDD to the SATA connector on
the adapter.
2. Connect the universal power adapter to the power adapter port
on the adapter and an electrical outlet.
Note: You can use most 2.5” drives without connecting the universal
power adapter, as enough power is provided through the USB
connection. If you use a 3.5” drive, you need to connect the universal
power adapter.
3. Connect the integrated USB-C connector to an available USB port
on your computer.
About driver installation
After you connect the adapter to your computer, the computer
detects the adapter and automatically installs the driver. You don’t
need to take any further action to install the driver.
Prepare a drive for use
Windows OS
If you connect a drive that already has data on it, after you connect
the adapter, it appears under My Computer Computer or with a
drive letter assigned to it.
If you install a brand-new drive that doesn’t contain any data, you
must prepare the drive for use.
Warning! When you complete the following steps, all of the data
on your drive will be deleted. If your drive has data on it that you
require, you should create a backup le or use a dierent drive.
SATA
connector
USB-C
connector
Power/activity
LED
Power adapter port
Probleemoplossing StarTech.com USB31C2SAT3
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 60 g |
| Breedte: | 25 mm |
| Diepte: | 87 mm |
| Hoogte: | 20 mm |
| Snoerlengte: | 1 m |
| Gewicht verpakking: | 324 g |
| Breedte verpakking: | 140 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 50 mm |
| Gebruikershandleiding: | Ja |
| Materiaal behuizing: | Kunststof |
| LED-indicatoren: | Activity, Power |
| Inclusief AC-adapter: | Ja |
| Certificering: | CE, FCC, REACH |
| Duurzaamheidscertificaten: | RoHS |
| Plug and play: | Ja |
| Aantal per verpakking: | 1 stuk(s) |
| Ingangsspanning: | 110 - 240 V |
| Temperatuur bij opslag: | -20 - 80 °C |
| Relatieve luchtvochtigheid: | 0 - 80 procent |
| Spanning: | 12 V |
| Chipset: | ASMedia - ASM1351 |
| Bedrijfstemperatuur (T-T): | 0 - 60 °C |
| Code geharmoniseerd systeem (HS): | 84733020 |
| Hot-swap: | Ja |
| Aansluiting 1: | USB Type-C USB 3.1 |
| Aansluiting 2: | 1 x SATA 7+15 pin |
| Aansluiting 1 type: | Mannelijk |
| Aansluiting 2 type: | Vrouwelijk |
| UASP-ondersteuning: | Ja |
