Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: January 16, 2023 9:41 AM
Product ID
109B-USBC-HDMI
Component Function
1 HDMI Output 1 • Connect to an HDMI Display
2 HDMI Output 2 • Connect to an HDMI Display
3 USB-C Host Connection • Connect to a USB-C Enabled Computer
4 USB-C to USB-A Adapter
• Connect to the USB-C Host Connection to use
with a USB-A Enabled Computer
5
Power Delivery Pass-
through Port
• Connect a USB-C Power Adapter
• USB Power Delivery 3.0 (up to 100W, with up to
90W available for host charging)
USB-C/USB-A to Dual HDMI - 4K 60Hz - 100W Power Delivery
Requirements
For the latest drivers/software, technical specications, and declarations of
conformance, please visit: www.StarTech.com/109B-USBC-HDMI
Package Contents
• USB-C/USB-A to HDMI Adapter x 1
• Quick-Start Guide x 1
Driver Installation
Installation is automatic for Windows 10 & up, and ChromeOS. If the drivers do
not auto-install, contact your IT administrator. If you are using macOS or another
supported operating system, the latest drivers are available at:
www.StarTech.com/109B-USBC-HDMI
Note: Operating system requirements are subject to change. For the latest
requirements, please visit: www.StarTech.com/109B-USBC-HDMI
Installation
Installing the Video Adapter
1. (Optional) Connect a USB-C Power Adapter (up to 100W) from an AC Outlet to the
USB-C Power Delivery Pass-through Port, located on the USB Video Adapter, to
charge the host computer.
Note: A USB-C Port with Power Delivery on the host is required for PD Pass-through
to charge the host. When using the USB-C to USB-A Adapter to connect to a USB-A
Host, PD Pass-through is not available.
2. Connect the USB Host Connection to an available USB-C or USB-A Port on the Host
Computer.
3. Connect an HDMI Cable (sold separately) from the HDMI Output 1 on the USB
Video Adapter, to an HDMI Display.
4. Connect an HDMI Cable (sold separately) from the HDMI Output 2 on the USB
Video Adapter, to an HDMI Display.
5. Arrange the display using the operating system’s Display Settings.
1
2
3
4
5
Probleemoplossing StarTech.com 109B-USBC-HDMI
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Grijs |
| Gewicht verpakking: | 180 g |
| Breedte verpakking: | 114 mm |
| Diepte verpakking: | 60 mm |
| Hoogte verpakking: | 16 mm |
| Materiaal behuizing: | Aluminium, Plastic |
| USB-connectortype: | USB Type-C |
| Maximum resolutie: | 3840 x 2160 Pixels |
| Aantal HDMI-poorten: | 2 |
| USB-versie: | 3.2 Gen 1 (3.1 Gen 1) |
| Interface adapters meegeleverd: | USB Type-A male - USB Type-C female |
| Ondersteunde grafische resoluties: | 1280 x 720 (HD 720),1920 x 1080 (HD 1080),2560 x 1440,3840 x 2160 |
| Duurzaamheidscertificaten: | CE, RoHS |
| Temperatuur bij opslag: | -20 - 70 °C |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Mac-compatibiliteit: | Ja |
| Audio-uitgangskanalen: | 5.1 kanalen |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C: | 1 |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ubuntu 18.04 LTS, Ubuntu 20.04 LTS |
| Snelle installatiehandleiding: | Ja |
| Andere ondersteundende systemen: | ChromeOS |
| USB Power Delivery: | Ja |
| Aantal displays ondersteund: | 2 |
| Chipset: | DisplayLink - DL6950 |
| USB kabel lengte: | 0.3 m |
| (Buitenste) hoofdverpakking hoogte: | 320 mm |
| (Buitenste) hoofdverpakking breedte: | 440 mm |
| (Buitenste) hoofdverpakking lengte: | 420 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 40 stuk(s) |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| HDMI-uitgang: | Ja |
| Geïntegreerde USB-kabel: | Ja |
| Geslacht USB-connector: | Mannelijk |
| USB-connector vormfactor: | Recht |
| DisplayPort-uitgang: | Nee |
| DVI-uitgang: | Nee |
