Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: October 6, 2023 11:25 AM
Product ID
PAX2235-WIFI-6E-CARD
PCIe Wi-Fi 6/6E Network Adapter Card - 802.11ax
Component Function
1 LED Indicator
• Solid Green: PCIe Wi-Fi Card is installed and
receiving power
2 Full Prole Bracket
• Secure the PCIe Wi-Fi Card to the Computer
Case
3 Antenna Connectors
• Connect the Antenna Cables from the Magnetic
Antenna Stand
4 Bluetooth USB 2.0 Header
• Connect to a USB 2.0 Header on the Computer’s
Motherboard, using the included Bluetooth
Cable
5 PCIe p1-x1 Connector
• Connect the PCIe Wi-Fi Card to a PCIe Slot in a
Computer
6 Magnetic Antenna Stand • Provides adjustable placement of the Antenna
Requirements
For the latest drivers/software, technical specications, and declarations of
conformance, please visit: www.StarTech.com/PAX2235-WIFI-6E-CARD
Package Contents
• PCIe Wi-Fi Card x 1
• Magnetic Antenna Stand x 1
• Bluetooth Cable x 1
• Low-Prole Bracket x 1
• Quick-Start Guide x 1
Installation
Warning: PCIe Cards can be damaged by static electricity. Ensure that the Installer
is properly grounded before they open the Computer Case or touch the PCIe Wi-Fi
Card. The Installer should wear an Anti-Static Strap when installing any computer
component. If an Anti-Static Strap is not available, discharge any built-up static
electricity by touching a large Grounded Metal Surface for several seconds. Only
handle the PCIe Wi-Fi Card by its edges and do not touch the gold connectors.
(Optional) Installing the Low Prole Bracket
Note: By default the Full Prole Bracket is attached to the PCIe Wi-Fi Card.
Depending on the system conguration the Full Prole Bracket may need to be
removed and replaced with the Low Prole Bracket (included).
1. Ensure the Antenna Cables are disconnected from the PCIe Wi-Fi Card.
2. Using a Small Phillips Head Screwdriver, remove the two Bracket Screws securing
the Full Prole Bracket to the PCIe Wi-Fi Card. Set the Bracket Screws aside as
they will be used to attach the Low Prole Bracket.
2
1
3
3
5
6
4
Probleemoplossing StarTech.com PAX2235-WIFI-6E-CARD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 200 g |
| Breedte: | 62 mm |
| Diepte: | 120 mm |
| Hoogte: | 18 mm |
| Snoerlengte: | 1 m |
| Gewicht verpakking: | 365 g |
| Breedte verpakking: | 107 mm |
| Diepte verpakking: | 150 mm |
| Hoogte verpakking: | 136 mm |
| LED-indicatoren: | Ja |
| Bluetooth: | Ja |
| Wi-Fi-standaarden: | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Bluetooth-versie: | 5.3 |
| Connectiviteitstechnologie: | Draadloos |
| Interface: | WLAN / Bluetooth |
| Bluetooth Low Energy (BLE): | Ja |
| Duurzaamheidscertificaten: | Federal Communications Commission (FCC) |
| Modulatie: | 1024-QAM, OFDMA |
| Wifi-band: | Tri-band (2,4 GHz / 5 GHz / 6 GHz) |
| Netwerkstandaard: | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ondersteunde beveiligingsalgoritmen: | AES, WPA2, WPA3 |
| Antenne versterkingsniveau (max): | 5 dBi |
| Temperatuur bij opslag: | -10 - 70 °C |
| Intern: | Ja |
| Ondersteunde WLAN data-overdrachtsnelheden: | 574,2402 Mbit/s |
| Frequentiebereik: | 2.4 - 6 GHz |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ja |
| Snelle installatiehandleiding: | Ja |
| Mean time between failures (MTBF): | 50000 uur |
| Hostinterface: | PCI |
| Maximale overdrachtssnelheid van gegevens: | 2400 Mbit/s |
| Montagebeugels meegeleverd: | Ja |
| Antenne: | Ja |
| Full duplex: | Ja |
| Component voor: | PC/Laptop |
| (Buitenste) hoofdverpakking hoogte: | 295 mm |
| (Buitenste) hoofdverpakking breedte: | 560 mm |
| (Buitenste) hoofdverpakking lengte: | 470 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 30 stuk(s) |
| Wifi: | Ja |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Antenne-ontwerp: | Extern |
| PCI versie: | 3.0 |
| MU-MIMO: | Ja |
