Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: October 4, 2023
Product ID
1P3FFCNB-USB-SERIAL
1P10FFCN-USB-SERIAL
Component Function
1Serial Port DB9 • Connect to a Serial Peripheral Device
2DB9 Screws
• Used to secure the to the Serial DB9 Port Serial
Peripheral Device
• The included can be installed for DB9 Nuts
compatibility with or Serial Peripheral Devices Cables
3LED Indicators
• Data Receive LED: Green Flashes to indicate activity
• Data Transmit LED: Yellow Flashes to indicate activity
• USB LED: BlueSolid to indicate driver has been
installed, and USB connection enumerated
4USB Type A Port
• Connect the to an available USB to Serial Adapter
USB-A Port
Pinout Diagram
FTDI USB-A to RS232 DB9 Null Modem Serial Adapter Cable - M/F
Package Contents
• USB to Serial Adapter x 1
• DB9 Nuts x 2
• Quick-Start Guide x 1
Requirements
• USB Type-A Enabled Computer x 1
For the latest drivers/software, product information, technical specications, and
declarations of conformance, please visit:
www.StarTech.com/1P3FFCNB-USB-SERIAL
www.StarTech.com/1P10FFCN-USB-SERIAL
Installation
Install the Driver and Adapter
Note: Drivers should install automatically in most supported operating systems. If
they do not, please complete the following steps:
1. Navigate to:
b. www.StarTech.com/1P3FFCNB-USB-SERIAL
c. www.StarTech.com/1P10FFCN-USB-SERIAL
4. Click the tab.Drivers/Downloads
5. Under , download the appropriate for your operating Driver(s) Driver Package
system.
Windows
1. Right-click the downloaded le and extract the contents with .Extract All
2. Browse the Windows folder and run the le.Setup
3. Follow the on-screen instructions to complete the installation.
4. Connect the to an available USB-A port.USB to Serial Adapter
macOS
1. Double-click the downloaded le.
2. Open the folder that matches your and run the le inside macOS Version Installer
the folder.
3. Follow the on-screen instructions to complete the installation.
4. Connect the to an available USB-A port.USB to Serial Adapter
43
1
Pin RS-232
1DCD
2TXD
3RXD
4DSR
5GND
6DTR
7CTS
8RTS
9RI
2
2
12345
6789
Probleemoplossing StarTech.com 1P3FFCNB-USB-SERIAL
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 55 g |
| Snoerlengte: | 1 m |
| Gewicht verpakking: | 84 g |
| Breedte verpakking: | 220 mm |
| Diepte verpakking: | 200 mm |
| Hoogte verpakking: | 25 mm |
| Gebruikershandleiding: | Ja |
| Duurzaamheidscertificaten: | RoHS |
| Temperatuur bij opslag: | -40 - 80 °C |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ja |
| Ondersteunde server operating systems: | Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2016, Windows Server 2012, Windows Server 2019, Windows Server 2022 |
| Chipset: | FTDI - FT232R |
| Bedrijfstemperatuur (T-T): | -40 - 80 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| Aansluiting 1: | USB Type-A |
| Aansluiting 2: | DB-9 |
| Connector 1 vormfactor: | Recht |
| Connector 2 vormfactor: | Recht |
| Aansluiting 1 type: | Mannelijk |
| Aansluiting 2 type: | Mannelijk |
| FIFO (First In, First Out): | 256 B |
| Materiaal buitenmantel: | Thermoplastische elastomeer (TPE) |
| Baud snelheid: | 921.6 Kbit/s |
| Bandwidth: | 480 MB/s |
| Data bits: | 7, 8 |
| Stop bits: | 1, 2 |
| Parity bit: | Even, Mark, N,Odd, Space |
