Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 17, 2021
Product Diagram (2P6GR-PCIE-SATA-CARD)
Front View
Port Function
1SATA Ports x 2
• Connect to the SATA Stoage Devices SATA
Controller Card SATA Cable using a
2
RAID Conguration
Jumper (J1)
• ON - Allow RAID to be congured
• OFF - Lock RAID conguration
3LED Headers
• LED Header
Connect LED to monitor activity of a connected
SATA Storage Device
• ERR Header
Connect to monitor errors in the LED RAID array
4PCIe p1-x2 Connector
• Connect the to the SATA Controller Card PCIe Slot
in the Computer
Product Information
For the latest product information, technical specications, manuals, and Declarations
of Conformance, please visit:
www.startech.com/2P6GR-PCIE-SATA-CARD.
Package Contents
• SATA Controller Card x 1
• Full-Prole Bracket (Installed) x 1
• Low-Prole Bracket x 1
• Quick-Start Guide x 1
2 Port SATA 6Gbps PCIe SATA Controller Card w/ RAID
Requirements
• Computer with an available PCIe slot (x4/8/16)
• Phillips Head Screwdriver
• SATA Cables
Hardware Installation
Warning: PCIe Cards can be damaged by static electricity. Make sure that the
Installer Computer Case is properly grounded before they open the or touch the
SATA Controller Card. The should wear an when Installer Anti-Static Strap
installing any computer component. If an is not available, discharge Anti-Static Strap
any built-up static electricity by touching a large for several Grounded Metal Surface
seconds. Only handle the by its edges and do not touch the SATA Controller Card
gold connectors.
Installing the Low-Prole Bracket
By default the is attached to the . Full-Prole Bracket SATA Controller Card
Depending on the system conguration it may be necessary to remove the Full-
Prole Bracket Low-Prole Bracket to replace with the (included).
1. Remove the 2x securing the , using a Phillips Head Screws Full-Prole Bracket
Phillips Head Screwdriver.
2. Remove the and replace with the Full-Prole Bracket Low-Prole Bracket
(included).
3. Install the 2x removed in step 1 and tighten, using a Phillips Head Screws Phillips
Head Screwdriver.
Installing the Card
1. Turn o the and any that are connected Computer Peripheral Devices
(e.g. printers, external hard drives, etc.).
2. Unplug the from the rear of the and disconnect any Power Cable Computer
Peripheral Devices that are connected.
3. Remove the from the . Cover Computer Case
Note: Consult the documentation that came with the for details about Computer
how to do this safely.
4. Locate an open (x4/8/16) and remove the corresponding PCIe Slot Metal Cover
Plate Computer Case Metal Cover Plate from the rear of the . In most instances, the
is attached to the rear of the with a single . Computer Case Phillips Head Screw
Save this for the next step. Phillips Head Screw
5. Gently insert the into the open (x4/8/16) and fasten SATA Controller Card PCIe Slot
the to the rear of the , using the Bracket Computer Case Phillips Head Screw from
step 4.
4
1
3
2
Probleemoplossing StarTech.com 2P6GR-PCIE-SATA-CARD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Rood |
| Gewicht: | 35 g |
| Breedte: | 69 mm |
| Diepte: | 22 mm |
| Hoogte: | 121 mm |
| Gewicht verpakking: | 126 g |
| Breedte verpakking: | 142 mm |
| Diepte verpakking: | 175 mm |
| Hoogte verpakking: | 30 mm |
| LED-indicatoren: | Ja |
| Duurzaamheidscertificaten: | RoHS |
| Temperatuur bij opslag: | -25 - 85 °C |
| Intern: | Ja |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Ondersteunt Linux: | Ja |
| Snelle installatiehandleiding: | Ja |
| Hostinterface: | PCIe |
| Ondersteunde server operating systems: | Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Montagebeugels meegeleverd: | Ja |
| Chipset: | ASMedia - ASM1062R |
| Soorten RAID: | 0, 1,BIG, JBOD |
| (Buitenste) hoofdverpakking hoogte: | 310 mm |
| (Buitenste) hoofdverpakking breedte: | 500 mm |
| (Buitenste) hoofdverpakking lengte: | 370 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 60 stuk(s) |
| Bedrijfstemperatuur (T-T): | 0 - 85 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Code geharmoniseerd systeem (HS): | 84733020 |
| S.M.A.R.T. support: | Ja |
| TRIM support: | Ja |
| Uitbreidingskaartstandaard: | PCIe 2.0 |
| Data transfer snelheid (max): | 6 Gbit/s |
| Aantal Internal SATA ports: | 2 |
| SATA herziening: | 3.0 |
| Output interface: | SATA |
| Poort-multiplier: | Ja |
