Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (DKT30CHVGPD)
Front View:
Side View:
Port/Connection Function
1USB-A Port • Connect a to the USB Device Host
2RJ45 Port • Connect a to the Network Device Host
3VGA Port • Connect a to the VGA Video Display Device
Host
4HDMI Port • Connect an to HDMI Video Display Device
the Host
Note: The is a single Multiport Adapter
video display adapter. You can connect either
an or a . HDMI Display VGA Display
5USB-C Host
Connector
• Connect the to the Multiport Adapter Host
• Power Delivery 3.0 (charging/power)
USB-C Multiport Adapter | HDMI | VGA | PD
1
6USB-C Power Port • Connect a to the USB-C Power Adapter
Host Computer
• Power Delivery 3.0 (charging/power)
Requirements
For the latest requirements, please visit .www.startech.com/DKT30CHVGPD
Powering the Multiport Adapter
USB Power Delivery 3.0
Fast Role Swap:
A Fast Role Swap function is available when using Power Delivery 3.0. This function
prevents USB data disruption when switching power sources (bus power to USB-C
power adapter or USB-C power adapter to bus power). For this function to work, the
host laptop must also support Power Delivery 3.0.
Bus Power:
The is powered by the and does not Multiport Adapter Host Computer’s USB-C Port
require a separate power adapter.
1. Connect the on the to a on the USB-C Connector Multiport Adapter USB-C Port
Host Computer.
2. The Host Computer’s operating system will automatically detect and install the
required driver.
Note: Host Computers that have a USB-C port that supports a maximum of 4.5W of
Bus Power will only get RJ45 Port functionality. All other ports on the Multiport Adapter
will be disabled due to insucient Bus Power.
USB-C Power Adapter:
The is powered using the Multiport Adapter Host Computer’s USB-C Power
Adapter Multiport Adapter. The maximum power delivery input is 95W. The requires
10W of Power Delivery capacity to power the and its connected Multiport Adapter
devices leaving a maximum power delivery of 85W for laptop charging.
Note: The Maximum Power Delivery is based on the limitations Multiport Adapter’s
of the .Host Computer’s USB-C Power Adapter
1. Connect the to a on the Multiport Adapter’s USB-C Connector USB-C Port Host
Computer.
2. Connect the on the to the USB-C Connector Host Computer’s Power Adapter
USB-C Power Port Multiport Adapter Universal Adapter on the . The will power
the and pass power through to the .Multiport Adapter Host Computer
2 4
3
5
6
Probleemoplossing StarTech.com DKT30CHVGPD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Black, Grey |
| Gewicht: | 254 g |
| Breedte: | 60 mm |
| Diepte: | 110 mm |
| Hoogte: | 18 mm |
| Snoerlengte: | 0.085 m |
| Gewicht verpakking: | 166 g |
| Breedte verpakking: | 142 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 30 mm |
| Materiaal behuizing: | Aluminium |
| Connectiviteitstechnologie: | Bedraad |
| Ethernet LAN: | Ja |
| Type stroombron: | USB |
| Geïntegreerde geheugenkaartlezer: | Nee |
| Snelstartgids: | Ja |
| VGA (D-Sub)poort(en): | 1 |
| Aantal HDMI-poorten: | 1 |
| Microfoon, line-in ingang: | Nee |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Certificering: | CE, FCC, REACH |
| Resolutie (maximum analoog): | 1920 x 1200 Pixels |
| Netvoeding: | 95 W |
| Resolutie (maximum digitaal): | 4096 x 2160 Pixels |
| Duurzaamheidscertificaten: | RoHS |
| Ethernet LAN, data-overdrachtsnelheden: | 10,100,1000 Mbit/s |
| Netwerkstandaard: | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Merkcompatibiliteit: | Alle merken |
| Temperatuur bij opslag: | -10 - 65 °C |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 1 |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Mac-compatibiliteit: | Ja |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C: | 1 |
| Hostinterface: | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Andere ondersteundende systemen: | ChromeOS |
| Auto MDI/MDI-X: | Ja |
| 10G support: | Nee |
| Full duplex: | Ja |
| Chipset: | VIA/VLI - VL102, Realtek - RTS5411, Parade Technologies - PS8338B, Parade Technologies - PS176, ITE Tech - IT6516, Realtek - RTL8153 |
| (Buitenste) hoofdverpakking hoogte: | 220 mm |
| (Buitenste) hoofdverpakking breedte: | 334 mm |
| (Buitenste) hoofdverpakking lengte: | 500 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 30 stuk(s) |
| Overdrachtssnelheid: | 5 Gbit/s |
| Stroomverbruik (typisch): | 10 W |
| Bedrijfstemperatuur (T-T): | 0 - 45 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| Code geharmoniseerd systeem (HS): | 84733020 |
| UASP-ondersteuning: | Ja |
