Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: February 22, 2023 1:29 PM
Product ID
PEX4SFF8639U3
Component Function
1LED Jumper Pins
• Connect to the LED Lights U.3 to PCIe p1-x4
Adapter Drive to show power/activity
• LED Lights not included
2
U.3 (SFF-TA-1001) Drive
Connector
• Connect a to U.3 (SFF-TA-1001) Storage Device
the U.3 to PCIe p1-x4 Adapter
3Drive Mounting Holes
• Secure the to the U.3 Storage Device U.3 to PCIe
x4 Adapter
4PCIe p1-x4 Connector
• Connect the to theU.3 to PCIe p1-x4 Adapter PCIe
Slot Computerin a
U.3 (SFF-TA-1001) to PCIe 4.0 p1-x4 Host Adapter for 2.5” U.3 NVMe SSDs
Requirements
For the latest drivers/software, technical specications, and declarations of
conformance, please visit: www.StarTech.com/PEX4SFF8639U3
Package Contents
• U.3 to PCIe p1-x4 Adapter x 1
• Drive Mounting Screws x 4
• Quick-Start Guide x 1
Installation
Connect an SSD to the Drive Adapter
Warning! Drives should be handled carefully, especially when being transported.
If not handled with care, lost or corrupted data may be experienced. Ensure that the
Installer Computer Case U.3 is properly grounded before opening the or touching the
to PCIe p1-x4 Adapter Installer . The should wear an when installing Anti-Static Strap
any computer component. If an is not available, discharge any Anti-Static Strap
built-up static electricity by touching a large for several Grounded Metal Surface
seconds. Only handle the U.3 to PCIe p1-x4 Adapter by its edges and do not touch the
gold connectors.
1. Carefully slide the into the and connect it to theSSD U.3 to PCIe p1-x4 Adapter U.3
(SFF-TA-1001) Connector on the card.
2. Turn over the .U.3 to PCIe p1-x4 Adapter
3. Use a and insert the four through Phillips Screwdriver Drive Mounting Screws
the on the and into the .Drive Mounting Holes U.3 to PCIe p1-x4 Adapter SSD
4. Tighten the to secure the drive to the .Screws U.3 to PCIe p1-x4 Adapter
Installing the Drive Adapter
1. Turn o the and any connected or (such as Computer Devices Peripherals
printers and external storage).
2. Unplug the from the back of the .Power Cable Computer
3. Disconnect any connected to the .Peripheral Devices Computer
4. Open the , referring to the documentation that came with the Computer Case
computer system for guidance.
4
1 2 3
