Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 19, 2020
Product Diagram (POEEXT1G60W)
Front View
Side View
Component Function
1PoE Output LED
Indicator
• Indicates the current status of the PoE Powered
Device (PD)
• ON - is activated and Power Source Equipment (PSE)
PD is detected
• OFF - is not detecting PSE PD
2PoE Input LED
Indicator
• Indicates the current status of the PSE
• ON - Power is detected
• O - Power is not detected
3PoE Input Port • PSE PoE Extender provides power and data to the
through a Network Cable
60W Industrial-Grade Hardened 802.3af/at PoE Extender 10/100/1000 Mbps
4PoE Output Port • The power and data is forwarded to the through a PD
Network Cable
5PoE Input and Output
LED Indicators
• Indicates the connection status and network speeds of
the and the PoE Input Port PoE Output Port
6Grounding Screw • Attach a to protect Grounding Wire Network
Equipment
Requirements
For the latest requirements, please visit .www.startech.com/POEEXT1G60W
• Power Source Equipment x 1
• Powered Device x 1
• RJ45 Terminated UTP/STP Cat 5e (or better) Network Cable (sold separately) x 2
• Earth Ground Connection x 1
• Ground Wire x 1
• (Optional) #2 Phillips Head Screwdriver x 1
• (Optional) Screws for Wall Mounting x 2
Installation
Grounding the PoE Extender
1. Using the loosen the on the Phillips Head Screwdriver Grounding Screw PoE
Extender.
2. Attach the to the . Grounding Wire Grounding Screw
3. Tighten the .Grounding Screw
4. Connect the other end of the to the .Grounding Wire Earth Ground Connection
Connecting the PoE Extender to an Existing PoE Connection
1. Connect a to the on a and to the Network Cable Output Port PSE Device PoE
Input Port PoE Extender on the .
2. Connect a to the on the and to the Network Cable PoE Output Port PoE Extender
Input Port PD on the .
Cascade PoE Extenders
1. Connect a to the on a and to the Network Cable Output Port PSE Device PoE
Input Port PoE Extender on the .
2. Connect a to the on the and to the Network Cable PoE Output Port PoE Extender
PoE Input Port PoE Extender on the next .
6
1
3 4
2
5
Probleemoplossing StarTech.com POEEXT1G60W
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 148 g |
| Breedte: | 81.5 mm |
| Diepte: | 104 mm |
| Hoogte: | 32 mm |
| Gewicht verpakking: | 390 g |
| Breedte verpakking: | 211 mm |
| Diepte verpakking: | 162 mm |
| Hoogte verpakking: | 64 mm |
| Soort: | Netwerkrepeater |
| Materiaal behuizing: | Aluminium |
| LED-indicatoren: | Ja |
| Snelstartgids: | Ja |
| Certificering: | CE, FCC |
| Duurzaamheidscertificaten: | RoHS |
| Ethernet LAN, data-overdrachtsnelheden: | 100,1000 Mbit/s |
| Netwerkstandaard: | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Mean time between failures (MTBF): | 551848 uur |
| Power over Ethernet (PoE): | Ja |
| Ondersteunde network protocollen (IPv4): | CSMA/CD |
| Datastroombeheer: | Ja |
| Chipset: | Realtek RTL8367, Microsemi PD69101 |
| (Buitenste) hoofdverpakking hoogte: | 225 mm |
| (Buitenste) hoofdverpakking breedte: | 355 mm |
| (Buitenste) hoofdverpakking lengte: | 345 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 10 stuk(s) |
| Maximaal bereik: | 100 m |
| Overdrachtssnelheid: | 1000 Mbit/s |
| Auto-negotiation: | Ja |
| Stroomverbruik (typisch): | 2.7 W |
| Bedrijfstemperatuur (T-T): | -40 - 75 °C |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Totaal Power over Ethernet (PoE)-budget: | 60 W |
| Hoeveelheid Power over Ethernet (PoE) ports: | 2 |
| Ondersteundende kabel types: | Cat5e, Cat6 |
