Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (ST8CU824)
Components Function
1Short-Circuit LEDs (8)
• Indicates that the correspondingSolid Red:
USB-A Port has shorted, and that the port has
been deactivated, to protect the connected
device.
• The port will remain deactivated until the
Charging Station is power-cycled.
2Power Button • Used to turn the On or O.Charging Hub
3DC IN 12V • Used to power the .Charging Hub
4USB-A Ports (8)
• Used to charge multiple (max = 8).Devices
• Voltage at the common collector (VCC) = 5V
• Ground (GND) = 5V
• D+ = 2.7V
• D- = 2.0V
8-Port Charging Station for USB Devices | 8x 2.4A
2
Requirements
For the latest requirements, please visit www.startech.com/ST8CU824
• Phillips Head Screwdriver (Optional)
Installation
Notes: The features a chipset that can detect the required charging Charging Hub
mode of a device, and switch to the proper mode for full-speed charging (e.g. If an
Apple device is connected, it will automatically charge to Apple charging mode
specications).
When charging multiple devices, the may become warm to the touch, Charging Hub
this is normal and will not harm the connected .Device(s)
1. Connect the to an and the other end to the Power Adapter AC Electrical Outlet DC
IN 12V Port Charging Hub on the .
2. Press the to turn the On. Power Button Charging Hub
3. Connect your to the corresponding on the .Device(s) USB-A Ports Charging Hub
Installing the Mounting Brackets (Optional)
Note: Before installing the to the mounting surface, contact a Mounting Bracket
professional. Product mounting should be completed by a certied professional as per
the local safety and building code guidelines.
1. Align the on the with the four Mounting Holes Mounting Bracket Mounting Holes
on the back of the .Charging Hub
2. Insert the (x4) through the and into the Bracket Screws Mounting Bracket
Mounting Holes Charging Hubon the back of the .
3. Tighten the using a , be careful not to Mounting Screws Phillips Head Screwdriver
over-tighten.
Installing the Rubber Feet (Optional)
1. Remove the from the .Rubber Feet Adhesive Strip
2. Align each of the on the back of the close to each of Rubber Feet Charging Hub,
the four corners.
3. Remove the adhesive backing and apply the to the .Rubber Feet Charging Hub
Note: Be careful not to cover the when applying the .Mounting Holes Rubber Feet
3
1
4
Manual Revision: May 4, 2022 4:11 PM
Probleemoplossing StarTech.com ST8CU824
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 272 g |
| Breedte: | 60 mm |
| Diepte: | 212 mm |
| Hoogte: | 25 mm |
| Type stekker: | Type M |
| Gewicht verpakking: | 1000 g |
| Breedte verpakking: | 240 mm |
| Diepte verpakking: | 154 mm |
| Hoogte verpakking: | 71 mm |
| LED-indicatoren: | Stroom |
| Stroom: | 2 A |
| Type stroombron: | AC |
| Aantal USB 2.0-poorten: | 8 |
| Certificering: | CE, FCC, UL, REACH, PSE, GS |
| Materiaal: | Aluminium |
| Duurzaamheidscertificaten: | RoHS |
| Ingangsspanning: | 100 - 240 V |
| AC-adapter, uitgangsstroom: | 8 A |
| Maximaal vermogen: | 96 W |
| Type oplader: | Auto |
| Lader compatibiliteit: | MP3, MP4, Mobile phone, PDA, Smartphone, Tablet |
| Uitgangsspanning (max): | 12 V |
| Bedrijfstemperatuur (T-T): | 5 - 35 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Werkingsprincipe: | Contact |
