日本語の取扱説明書は裏面をご覧ください。
INSTRUCTION MANUAL
AC ADAPTER AD-1215P
Thank you for purchasing TOA's AC Adapter.
Please carefully follow the instructions in this manual to
ensure long, trouble-free use of your equipment.
1. GENERAL DESCRIPTION
The AD-1215P is a dedicated AC adapter to operate the
Packet Intercom IP Stations on AC power. Never use it for
other equipment.
2. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the
instructions in this section for correct and safe operation.
• Be sure to follow all the precautionary instructions in
this section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future reference.
Indicates a potentially hazardous situation which, if
mishandled, could result in death or serious personal
injury.
WARNING
• Do not expose the unit to rain or an environment where
it may be splashed by water or other liquids, as doing
so may result in re or electric shock.
• Use the unit only with the voltage specied on the unit.
Using a voltage higher than that which is specied may
result in re or electric shock.
• Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the power
cord in close proximity to heaters, and never place
heavy objects -- including the unit itself -- on the power
cord, as doing so may result in re or electric shock.
• Should the following irregularity be found during use,
immediately, disconnect the power supply plug from
the AC outlet and contact your nearest TOA dealer.
Make no further attempt to operate the unit in this
condition as this may cause re or electric shock.
· If you detect smoke or a strange smell coming from
the unit.
· If water or any metallic object gets into the unit
· If the unit falls, or the unit case breaks
· If the power supply cord is damaged (exposure of the
core, disconnection, etc.)
• To prevent a re or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit.
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
CAUTION
• Never plug in nor remove the power supply plug with
wet hands, as doing so may cause electric shock.
• Avoid installing the unit in humid or dusty locations, in
locations exposed to the direct sunlight, near the heaters,
or in locations generating sooty smoke or steam as doing
otherwise may result in re or electric shock.
• Remove the power supply plug from the AC outlet when
moving the connected equipment, as doing otherwise
may cause damage to the power cord, resulting in a re.
• If dust accumulates in the wall AC outlet, a re may
result. Clean it periodically.
• Unplug the power supply plug from the AC outlet for
safety purposes when cleaning or leaving the unit
unused for 10 days or more. Doing otherwise may
cause a re or electric shock.
3. CHECKUP AND REPLACEMENT
Periodical checkup and replacement are required to ensure
trouble-free use of the AC Adaptor. Replace it in about
6 years as a guide when used 24 hours every day under
normal use conditions. This 6-year period is suggested
only as a guide, and may be shortened depending on the
installation environment and conditions of use.
5. SPECIFICATIONS
Power Source 100 to 240 V AC, 50/60 Hz
Output 12 V DC, 1.5 A
Current Consumption 0.5 A,
AC Input 100 V (rated output)
Cord Length 1.8 m (5.91 ft)
Plug (Conductor) Conductor: Positive tip,
ø5.5 x ø2.1 x L 9.5 mm (0.37")
Operating Temperature 0 to 40°C (32 to 104ºF)
Finish Case: Polycarbonate, black
Weight 170 g (0.37 lb)
Note: The design and specications are subject to change
without notice for improvement.
4. DIMENSIONAL DIAGRAM
34
(1.34")
17 (0.67") 52 (2.05")
69 (2.72")
1800 (5.91 ft)
9.5 (0.37")
Unit: mm
72 (2.83")
URL: https://www.toa.jp/
133-06-00043-00
