PCE-5B06V(7B06V)-04A1E Startup Manual 1
PCE-5B06V-04A1E (PCE-7B06V-04A1E) Backplane: 6-slot BP for 2U Chassis,
1PICMIG 1.3, 1 PCIe, 4 32-bit PCI
PCE-5B06V-04A1E (PCE-7B06V-04A1E) Backplane:
6-slot BP for 2U Chassis, 1 PICMIG 1.3, 1 PCIe, 4
32-bit PCI
Startup Manual
Before you begin installing your card, please make sure
that the following materials have been shipped:
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Standard Functions
• PICMIG 1.3 slots:
PCE-7B06V-04 supports PCE-7xxx CPU boards
PCE-5B06V-04 supports PCE-5xxx CPU boards
• PCIe slots:
PCE-7B06V-04 supports one PCIe p1-x8 slot
PCE-5B06V-04 supports one PCIe x16 slot
• 32-bit PCI:
Four 32-bit / 33 MHz PCI slot
• USB (2.0) support: Four Universal Serial Bus ports to
Backplane
Mechanical and Environment
• Dimensions: 80.01 x 325 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
• Power requirements: Refer to the CPU Board, add-on
Card & Peripherals
• Operating temperature: 0 ~ 60° C
• Weight: 0.211 kg (weight of board)
Packing list Specifications
• One 2 Ports USB Cable p/n: 1700002204
• PCE-5B06V-04A1E (PCE-
7B06V-04A1E) Startup Manual
• M4*6*0.7 Round Screws (5 pcs)
p/n: 1939000410
• 2 years quality warranty card p/n: 2190000902
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B06V-04A1E (PCE-
7B06V-04A1E) series Rev. A1
Part No. 200K5B0621
Printed in China
2nd Edition
August 2012
