Crestron FTA-CP Series
Connector Plates
Installation Guide
INSTALLATION
To install an FTA-CP Series Connector Plate in a
Crestron® FT Series FlipTop™, use the following
procedure:
1. Remove the two #06-32 x 1/4" screws holding the
original, blank plate in place.
Connector Plate Screw Locations
(FT-600 Shown)
2. Remove the original, blank plate.
3. Place the new connector plate in position.
4. Secure the new connector plate using the two
screws removed in step 1.
Crestron Electronics, Inc. Installation Guide
15 Volvo Drive DOC. 7613A
Rockleigh, NJ 07647 (2038834)
Tel: 888.CRESTRON 11.13
Fax: 201.767.7576 Specifications subject to
www.crestron.com change without notice.
Further Inquiries
To locate specific information or resolve questions after
reviewing this guide, contact Crestron's True Blue Support at
1-888-CRESTRON [1-888-273-7876] or, for assistance within
a particular geographic region, refer to the listing of Crestron
worldwide offices at www.crestron.com/offices.
To post a question about Crestron products, log onto
Crestron’s Online Help at www.crestron.com/onlinehelp.
First-time users must establish a user account to fully benefit
from all available features.
Future Updates
As Crestron improves functions, adds new features, and
extends the capabilities of the FTA-CP Series, additional
information may be made available as manual updates. These
updates are solely electronic and serve as intermediary
supplements prior to the release of a complete technical
documentation revision.
Check the Crestron website periodically for manual update
availability and its relevance. Updates are identified as an
“Addendum” in the Download column.
06-32 x 1/4” Screws (2)
Probleemoplossing Crestron FTA-CP-RJ45-102
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 21 mm |
| Diepte: | 88 mm |
| Hoogte: | 39 mm |
| Aantal per verpakking: | 1 stuk(s) |
| Constructietype: | Plat |
| Aansluiting 2: | 2x RJ-45 |
| Aansluiting 1 type: | Vrouwelijk |
| Aansluiting 2 type: | Vrouwelijk |
