cAP ac series
The cAP is a ceiling mountable wireless access point. It is already configured, you can simply plug in your ISP
cable and start using wireless Internet. We recommend you to set up a password to secure your device.
As with any MikroTik wireless access point, you can also manage it using the CAPsMAN wireless access point
management server. In this case, all configuration will be done in CAPsMAN. See Buttons and jumpers on how to
set this device as a managed CAP.
Powering
The device only accepts powering from the first ethernet port with PoE, so you must either use the included passive
PoE injector, or make sure your switch supports passive or 802.3af/at PoE output. The power consumption under
maximum load can reach 13W.
Setup
1. Connect your Internet cable to the first port.
2. Set your computer IP configuration to automatic (DHCP).
3. From your computer, connect to the wireless network name which starts with “MikroTik”.
4. Once connected to the wireless network, open http:// 192.168.88.1 in your web browser to start
configuration since there is no password by default, you will be logged in automatically. Set up your ,
password in the screen that loads. Please also specify your country, to comply with local regulations.
Configuration
By default, the device is configured as a wireless access point, with the first ethernet port (Eth1) configured as a
DHCP client, and the second interface bridged together with the wireless interface. A DHCP server is configured on
the bridge interface.
RouterOS includes many configuration options in addition to what is described in this document. We suggest to
start here to get yourself accustomed to the possibilities: . http://mt.lv/help
In case IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC http://mt.lv/winbox
address of the device from the LAN side (all access is blocked from the internet port by default).
For recovery purposes, it is possible boot the device from network, see section Buttons and jumpers.
Extension slots and ports
Two ethernet ports that support automatic cross/straight cable correction (Auto MDI/X), so you can use
either straight or cross-over cables for connecting to other network devices. The Eth2 port is capable of
powering another RouterBOARD device with passive PoE (up to 57 V). The maximum output current is
500mA when using less than 30V to power this device and 400mA when using more than 30V.
Integrated wireless module which supports AP/CPE/P2P/repeater modes.
See www.mikrotik.com support@mikrotik.com for more information or contact Document #34673. Modified on 13-Apr-18
Probleemoplossing Mikrotik cAP ac
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Breedte verpakking: | 145 mm |
| Diepte verpakking: | 145 mm |
| Hoogte verpakking: | 30 mm |
| Plaatsing: | Muur |
| Frequentie van processor: | 716 MHz |
| Processormodel: | Qualcomm Atheros IPQ4018 |
| Aantal processorkernen: | 4 |
| Wi-Fi-standaarden: | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Inclusief besturingssysteem: | RouterOS |
| USB-poort: | Nee |
| Ethernet LAN: | Ja |
| Type stroombron: | AC |
| Inclusief AC-adapter: | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten: | 2 |
| Vermogensverbruik (max): | 13 W |
| Intern geheugen: | 128 MB |
| Type processor: | Ja |
| SIM-kaartsleuf: | Nee |
| 3G/4G USB modem compatibiliteit: | Nee |
| Geheugenkaart slot(s): | Nee |
| Wifi-band: | Dual-band (2.4 GHz / 5 GHz) |
| Wifi-standaard: | Wi-Fi 4 (802.11n) |
| WLAN gegevensoverdrachtsnelheid (max): | 54 Mbit/s |
| Interfacetype Ethernet LAN: | Gigabit Ethernet |
| Ethernet LAN, data-overdrachtsnelheden: | 10,100,1000 Mbit/s |
| Netwerkstandaard: | IEEE 802.3af,IEEE 802.3at |
| Soort antenne: | Intern |
| Antenne versterkingsniveau (max): | 2.5 dBi |
| 3G: | Nee |
| 4G: | Nee |
| Intern: | Nee |
| Ethernet WAN: | Nee |
| Flash memory: | 16 MB |
| Maximale overdrachtssnelheid van gegevens: | 54 Mbit/s |
| 2,4 GHz: | Ja |
| 5 GHz: | Ja |
| Power over Ethernet (PoE): | Ja |
| DSL WAN: | Nee |
| AC-ingangsspanning: | 17 - 57 V |
| Stroomverbruik (typisch): | 13 W |
| Bedrijfstemperatuur (T-T): | -40 - 50 °C |
| Antenne-ontwerp: | Intern |
