For Technical Support: www.panduit.com/resources/install_maintain.asp

INSTALLATION INSTRUCTIONS

CONTENTS: (#) indicates FMT2A quantity

OPTICOM QUICKNET Rack Mount Angled Fiber

Cassette Enclosures and Patch Panels

Part Numbers: FMT1A, FMT2A, CFAPPBL1A, CFAPPBL2A

1 - ENCLOSURE

1 (2) - #10-32 x 5/16" SCREWS

4 (5) - #10-32 HEX NUTS

4 - #12-24 x 1/2" SCREWS

4 - M6 x 1 SCREWS

3 - #10 FLAT WASHERS

1 (2) - CABLE ENTRY GROMMET(S)

1 (2) - STRAIN RELIEF BRACKET(S)

2 - ADHESIVE BEVEL ENTRY CLIPS

2 - ADHESIVE BACKED MOUNTS

4 - TAK-TYs (6" pcs.)

2 - SLACK SPOOLS (FMS1 or FMS2)

Cover (field removable)

Fiber Adapter Panels (FAPs):

Up to 4 for FMT1A

Up to 8 for FMT2A

(sold separately) Trunk or Interconnect

Cable Entry Grommet

Strain Relief Bracket

Enclosure

CFAPPBL1A

CFAPPBL2A

PG16 Gland

(customer supplied)

1 - CAUTION LABEL

1 - LASER WARNING LABEL

Page 1 of 8

Angled Patch Panel

(CFAPPBL1A shown)

FMT1A FMT2A

(sold separately)

ASSEMBLY VIEW showing Fiber Adapter Panels (FAPs) - sold separately

CAUTION:

Fiber optic cable is sensitive to excessive pulling, bending and crushing forces. Consult the manufacturer’s cable specification sheet for

the specific cable in use.

Follow TIA/EIA-568A, 569, 606, and 607 installation guidelines where applicable.

Care should be taken when opening and closing fully loaded drawer in order to protect fiber components.

WARNING: UNMATED CONNECTORS MAY EMIT INVISIBLE LASER RADIATION. DO NOT LOOK DIRECTLY INTO THE END OF THE

CONNECTOR. DO NOT INSPECT WITH MAGNIFYING DEVICES. MAINTAIN CAP ON UNMATED CONNECTORS.
