FOR TECHNICAL SUPPORT www.panduit.com/resources/install_maintain.asp
INSTRUCTIONS CM337
© Panduit Corp. 2007
Cam Hook
Lock Washer
Key
Lock Body
Lock Guide
Lock
Nut
Page 1 of 2
P ZAN ONE Building Automation Systems
Enclosure Accessories
PZBASELK Installation:
Knockout the two large holes directly opposite from the hinges on the cover. Slide in lock body through hole from outside of door.
Then slide lock washer, lock guide, and locknut onto lock body from inside the door. Attach lock hook with supplied screw.
(See figure below). Make sure hook on lock is facing down as shown above.
Lock Guide
PZBASELK
PZAEFAN
