8-Port HDMI, IR, RS232 and
Power Extender Rack
Over Cat5e/6
CONSOLIDATE UP TO EIGHT
4K HDMI EXTENDERS IN ONE
POWERED RACK UNIT
TO TRANSMIT HD SIGNALS
UP TO 450 FEET AWAY
USING CAT5E/6 CABLES
Quick Start Guide
VIDEO
Format HDMI 1.3 (HDCP Compliant)
Resolutions
800x600, 1024x768, 1280x1024,
1366x768, 1920x1200, 480i,
720p, 1080i,1080p,
4K x 2K @30Hz @24bit
Transmission Distance 450 feet (135 meters)
Color Depth
Deep Color 36/30/24 Bit at 1080p
and 3D
Audio Format
Up to PCM 8 channel, Dolby Digital
TrueHD, and DTS-HD Master Audio
IR Range 38kHz, 56kHz
Video Bandwith 10.2Gbps
Input Video Signal 1.2 Volts P-P
Input DDC Signal 5 Volts (TTL)
I/O CONNECTOR (Transmitter)
Input (8) HDMI-A 19-pin (female)
Output (8) RJ45 Jack
I/O CONNECTOR (RECEIVER)
Input (1) RJ45 Jack
Interface
(1) 3.5mm Jack for IR Emitter
(1) HDMI-A 19-pin (female)
OTHER
Power Internal 110/220V
Dimensions 17”W x 3.6”H x 3”D
Weight 4.3 lbs
Approvals UL, CE, ROHS Compliant
Operating Temp. 0 to 40° C (32° to 104° F)
Storage Temp. -20° to 60°C (-4° to 140° F)
Humidity 10% to 85% (Non-condensing)
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
RK8-HDX-ULT
WHAT’S IN THE BOX
PART NO. DESCRIPTIONQ-TY
RK8- HDX-ULT-TX 1
HDMI, RS232 and IR 8-Port
Rackmount Transmitter over
a Single Cat5e/6 Cable
Power Cord 1 CCWPWR
Quick Start Guide 1
