© Copyright 2010 Smart-AVI, All Rights Reserved
NOTICE
The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
2840 N. Naomi Ave. Burbank, CA 91504
Tel: (818) 565-0011 Fax: (818) 565-0020
http://www.SmartAVI.com
Compensates for Skew Caused by Long
Runs of Twisted Pair Cable
VSA-100
Smart Video Skew Adjuster
www.smartavi.com
Installation
Manual
Technical Specications
What’s in the Box?
PART NO. QTY DESCRIPTION
VSA-100S 1 Skew for all VGA receivers Includes: [VSA-
100, (CCVGAMM06), and (PS5VD2A)]
Power Supply 1 PS5VDC2A
User Manual 1
VIDEO
Format VGA RGB Analog (75Ω, 0.7Vp-p)
Resolution Up to 1600x1200 @ 85Hz2048x1536 @ 60Hz
Input Interface (1) HD-15 Female
Output Interface (1) HD-15 Female
Total, Step Delay 62ns, 2ns
H Frequency Range 30-95KHz
V Frequency Range 50-180Hz
OTHER
Power External 5VDC2A
Dimensions 5”W x 1.25”H x 2.5”D
Weight 0.3 lbs.
Approvals Device: CE, ROHS; Power Supply: C-UL US, CE
Probleemoplossing Smart-AVI VCA-RX100S
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Soort: | AV-receiver |
| LED-indicatoren: | Ja |
| Stroom: | 0.5 A |
| Ondersteunde video-modi: | 1080i, 1080p, 720p |
| Maximum resolutie: | 1920 x 1200 Pixels |
| Aansluiting voor netstroomadapter: | Ja |
| Ondersteunde grafische resoluties: | 1024 x 768 (XGA), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Externe adapter: | Ja |
| RJ-45 invoer ports: | 1 |
| VGA (D-Sub) uitgang ports: | 1 |
| Operating voltage: | 5 V |
| Maximaal bereik: | 300 m |
| Wifi: | Nee |
| Ondersteundende kabel types: | Cat5, Cat5e, Cat6, Cat7 |
