Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: May 27, 2024
Product ID
AF212C-POE-INJECTOR
Top
1-Port 802.3at 30W 2.5Gbps PoE+ Injector
Component Function
1Mounting Holes Mount the to an appropriate surface• PoE Injector
2Power Input Connect the included • 6ft (1.8m) NA Power Cord
3Power LED is receiving power• Solid Green: PoE Injector
4
PoE+ Port
(Data + PoE)
• Connect an to a Ethernet Cable PD (Powered
Device)
• Supports , , and 2.5Gbps, 1Gbps 100Mbps
10Mbps
• Supports and 802.3af 802.3at
5Data Port
• Connect an to a Ethernet Cable Network Device
• Supports , , and 2.5Gbps, 1Gbps 100Mbps
10Mbps
Product Information
For the latest product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/AF212C-POE-INJECTOR
Requirements
• Network Cables x 2
Package Contents
• PoE Injector x 1
• 6ft (1.8m) NA Power Cord x 1
• Quick-Start Guide x 1
Installation
(Optional) Mount the PoE Injector
1. Determine the and for the . Mounting Surface Location PoE Injector
2. Mount the to the desired using the appropriate PoE Injector Mounting Surface
Mounting Hardware Mounting Holes(e.g. Wood Screws) through the built-in .
Install the PoE Injector
1. Connect an from the (i.e., router, modem, or Ethernet Cable Source Network Device
non-PoE switch) to the on the . Data Port PoE Injector
2. Connect an to the on the . Ethernet Cable PoE+ Port PoE Injector
3. Connect the other end of the used in to either a Ethernet Cable Step 2 PD (Powered
Device) PoE Splitter Data Poweror a to separate and .
4. Plug the included into an and connect it to the NA Power Cord AC Outlet
Power Port, PoE Injector Power LEDlocated on the rear of the . Verify that the is
illuminated.
1
1
3
2
4
5
