Instruction manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 08/13/2015
For the latest information, technical specications, and support for
this product, please visit www.startech.com/FCREADUOTGDB.
Packaging contents
• 1 x memory card reader dongle
• 1 x instruction manual
System requirements
• A device (smartphone, tablet, and so on) that is enabled with
Micro USB On-The-Go technology
System requirements are subject to change. For the latest
requirements, please visit www.startech.com/FCREADUOTGDB.
FCREADUOTGDB
Memory Card Reader Dongle - Micro USB On-The-Go
*actual product may vary from photos
Product diagram
Introduction
The memory card reader dongle enables you to connect your
portable devices with USB OTG, such as a smartphone or a tablet, to
a wide variety of memory cards including SD cards, Micro SD cards,
USB ash drives, or HDDs.
Use the memory card reader
To access the data stored on your SD card, Micro SD card, or USB
ash drive, complete the following:
1. Depending on the type of memory card that you’re using, insert
the memory card in the appropriate slot on the memory card
reader.
2. Connect the integrated Micro USB 2.0 cable on the memory card
reader to the Micro USB port on your portable device, such as a
smartphone or tablet.
3. Access the stored data on the connected portable device.
Note: The memory card reader doesn’t require a power source for
standard card reader operations.
Connect a USB peripheral device
1. Connect the USB cable from the peripheral device to the USB A
port on the memory card reader.
2. Connect a Micro USB cable (not included) to the power source
port on the card reader to an available USB power source.
3. If you require additional power, connect the integrated Micro USB
2.0 cable on the memory card reader to the Micro USB port on
your portable device, such as a smartphone or tablet.
About the LED indicators
The memory card reader has two LED indicators located on the top
of the unit. For more information about what the LEDs indicate,
consult the tables below.
Yellow power LED
LED behavior Signies
LED is not illuminated There is no power source connected to
the memory card reader.
LED is illuminated A power source is connected to the
memory card reader.
Blue link and activity LED
LED behavior Signies
LED is not
illuminated
No memory cards are inserted in the
memory card reader.
LED is illuminated A memory card is inserted in the memory
card reader.
LED is blinking The memory card reader is completing a
process.
Micro USB 2.0 input
Power source
port
Micro SD card slot
USB A port
SD card slot
Probleemoplossing StarTech.com FCREADUOTGDB
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 56 mm |
| Diepte: | 195 mm |
| Hoogte: | 13 mm |
| Gewicht verpakking: | 70 g |
| Breedte verpakking: | 142 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 30 mm |
| Materiaal behuizing: | Kunststof |
| LED-indicatoren: | Activity, Link, Power |
| Type stroombron: | USB |
| Compatibele geheugenkaarten: | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| Snelstartgids: | Ja |
| Aantal USB 2.0-poorten: | 1 |
| Certificering: | RoHS, CE, FCC |
| Plug and play: | Ja |
| Temperatuur bij opslag: | -20 - 60 °C |
| Intern: | Nee |
| Soort aansluiting: | USB 2.0 |
| Overdrachtssnelheid: | 480 Mbit/s |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 80 procent |
| Geïntegreerde USB-kabel: | Ja |
| UASP-ondersteuning: | Nee |
| Chips organisatie: | GL823U |
