Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 02/16/2017
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/SDMSDRWU3AC.
Package contents
• 1 x card reader/writer
• 2 x end caps
• 1 x quick-start guide
Requirements
• microSD or SD card
• Computer, tablet, laptop, or smartphone equipped with a USB-C or
USB-A port
Note: To obtain the maximum USB throughput, you must use a
system with a USB 3.0 port.
The SDMSDRWU3AC is OS independent and doesn’t require any
additional drivers or software.
The card reader/writer receives enough power through the USB bus
and doesn’t require an additional power source.
Requirements are subject to change. For the latest requirements,
please visit www.StarTech.com/SDMSDRWU3AC.
SDMSDRWU3AC
USB 3.0 Memory Card Reader/Writer for SD and microSD cards - USB-C and USB-A
*actual product may vary from photos
Introduction
The SDMSDRWU3AC provides a quick and easy way to access
data stored on SD™ cards and microSD™ cards, and supports data
transfer speeds up to 5Gbps. You can use this card reader/writer
with a computer, tablet, laptop, or smartphone that’s enabled with a
USB-C™ or USB-A port.
Product diagram
Removable end cap
USB-C connector
(not pictured)
USB-A connector
(not pictured)
Activity LED
microSD card slot
SD card slot
Removable end cap
About USB 3.0 and USB 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard
oers speeds up to 5Gbps. Any mention of USB 3.0 in this manual or
on the StarTech.com website in relation to SDMSDRWU3AC refers to
the 5Gbps USB 3.1 Gen 1 standard.
Note: Data transfer rates are dependent upon the speed of the
memory card you are using and the speed capabilities of the USB
port on your device.
About the LED indicator
The SDMSDRWU3AC features a blue located to the Activity LED
left of the card slots. The blinks to indicate that data is Activity LED
being transferred.
Avoid disconnecting the card reader/writer when the is Activity LED
blinking.
Connect the card reader/writer
1. Gently slide a memory card into the appropriate card slot on the
SDMSDRWU3AC until you feel resistance and the card is fully
inserted.
2. Do one of the following:
• Insert the on the card reader/writer into the USB-C connector
USB-C port on your computer, tablet, laptop, or smartphone.
• Insert the on the card reader/writer into the USB-A connector
USB-A port on your computer, tablet, or laptop.
3. To access the content on your memory card, follow the
instructions specic to the operating system that you’re running.
When you connect the card reader/writer, your system automatically
detects and installs the required software.
Caution! Do not insert two cards into the card reader/writer at the
same time. You can only access the data stored on one card at a time.
Probleemoplossing StarTech.com SDMSDRWU3AC
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 11.8 g |
| Breedte: | 20 mm |
| Diepte: | 78 mm |
| Hoogte: | 11 mm |
| Gewicht verpakking: | 38 g |
| Breedte verpakking: | 70 mm |
| Diepte verpakking: | 105 mm |
| Hoogte verpakking: | 20 mm |
| Materiaal behuizing: | Kunststof |
| LED-indicatoren: | Activity, Power |
| Maximale capaciteit van de geheugenkaart: | 2000 GB |
| Compatibele geheugenkaarten: | MMC, MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| Snelstartgids: | Ja |
| Certificering: | CE, FCC, RoHS |
| Plug and play: | Ja |
| Temperatuur bij opslag: | -20 - 70 °C |
| Intern: | Nee |
| Soort aansluiting: | USB 3.2 Gen 1 (3.1 Gen 1) Type-A/Type-C |
| (Buitenste) hoofdverpakking hoogte: | 175 mm |
| (Buitenste) hoofdverpakking breedte: | 290 mm |
| (Buitenste) hoofdverpakking lengte: | 425 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 100 stuk(s) |
| Overdrachtssnelheid: | 5000 Mbit/s |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 50 - 90 procent |
| Code geharmoniseerd systeem (HS): | 84719000 |
| Chips organisatie: | Genesys Logic - GL3224 |
