StarTech.com FCREADHCU3 Handleiding
Hier is de StarTech.com FCREADHCU3 (Geheugenkaartlezer) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 0.5 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
I T: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
P T: Guia do usuário - pt.startech.com
Manual Revision: 10/06/2014
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1 x USB 3.0 Card Reader
• 1 x USB 3.0 Cable
• 1 x Instruction Manual
System Requirements
• USB enabled computer system with available USB port
• Microsoft® Windows® XP/ Server 2003/ Vista/ Server 2008 R2/ 7
(32/64-bit)
FCREADHCU3
External USB 3.0 Flash Memory Card Reader
Installation
1. While the computer is running, connect the USB cable from the
back of the card reader, to an available USB port on the host
computer. The LED on the top of the card reader will light up.
2. Windows will automatically detect the card reader and install the
drivers.
3. Once the drivers are installed, the card reader will be ready for
use.
4. Gently insert a memory card into the appropriate card slot, with
the label side facing up. The card should not have to be forced.
5. Access the memory card like any other removable storage device,
from the “My Computer” window.
6. To remove the memory card, make sure it is not currently being
accessed, and simply pull the card the card from the slot.
Card Slot 1 CompactFlash® type I/II
Card Slot 2
Memory Stick® (MS), MS Duo, MS PRO,
MS Select, MS PRO Duo, MS-ROM, MSXC
*MagicGate™ and High Speed modes supported
Card Slot 3 MicroSD, MicroSDHC, Memory Stick Micro (M2)
Card Slot 4
Secure Digital® (SD), SDHC, SDXC,
MultiMediaCard™ (MMC), DV-MMC, RS-MMC,
DV-RS MMC, MMCplus, MMCmobile
1 2
3
4
Front View
Rear View *actual product may vary from photos
USB 3.0 Connector (host)
Probleemoplossing StarTech.com FCREADHCU3
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 54 g |
| Breedte: | 55 mm |
| Diepte: | 85 mm |
| Hoogte: | 20 mm |
| Gewicht verpakking: | 169 g |
| Breedte verpakking: | 143 mm |
| Diepte verpakking: | 173 mm |
| Hoogte verpakking: | 32 mm |
| Gebruikershandleiding: | Ja |
| Materiaal behuizing: | Kunststof |
| LED-indicatoren: | Stroom |
| Stroom: | 0.8 A |
| Meegeleverde kabels: | USB |
| Compatibele geheugenkaarten: | CF, Memory Stick (MS), MicroSD (TransFlash), MicroSDHC, MiniSD, MMC, MS Duo, MS Micro (M2), MS PRO, MS PRO Duo, MS Pro-HG Duo, MSXC, RS-MMC, SD, SDHC, SDXC |
| Certificering: | CE, FCC, RoHS |
| Plug and play: | Ja |
| Ingangsspanning: | 100 - 240 V |
| Temperatuur bij opslag: | -65 - 150 °C |
| Intern: | Nee |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Ondersteunt Linux: | Ja |
| Output current: | 4000 mA |
| Spanning: | 5 V |
| Soort aansluiting: | USB 3.2 Gen 1 (3.1 Gen 1) |
| Chipset: | Genesys Logic - GL3220 |
| Bedrijfstemperatuur (T-T): | -40 - 80 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 90 procent |
| Code geharmoniseerd systeem (HS): | 84719000 |
| SIM card support: | Nee |
