Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: December 5, 2024
Rear Side
Front Side
Product ID (HB31C5A2CME)
7-Port Industrial USB-C Hub - USB 3.2 10Gbps, ESD Protection
Component Function
1DC Power Input 7~24 V • Connect a + DC Power Source
2
DC 2-Wire Terminal Block
Power Input
• Connect a +7~24 V DC Power Source
3
Screw Locking USB-C Host
Port
• Connect to a USB-C or USB-A Port on a Host
Computer
• USB 3.2 Gen 2 (10 Gbps)
Product Diagram
1 2
4
3
6
7
4Power LED
• Indicates if the USB hub is receiving power
from either a USB Host or a DC Power Source
• Solid Green - Receiving Power
• O - Not Receiving Power
5Mounting Brackets
• Wall mount the USB Hub
• Mount the USB Hub to the side/underside of
a Desk
6
7x Screw Locking USB
Data/Charge Ports
(5x USB-A / 2x USB-C)
• Connect to USB-A and USB-C Peripherals
• USB 3.2 Gen 2 (10 Gbps)
• USB-A Ports Support BC 1.2 for up to 5
V/1.5 A (7.5 W) Charging
• USB-C Ports Support up to 5 V/3 A (15 W)
Charging
77x USB Port Status LEDs
• Indicates if a USB Peripheral is Connected to
the Corresponding Port
• Solid Green - USB Peripheral is Connected
• O - USB Peripheral is Not Connected
Requirements
Host Computer
• USB-C or USB-A Port
Mounting Tools (Optional)
• Mounting Screws x 2
• Phillips or Flat Head Screwdriver
• Writing Utensil
• Level
For the latest drivers, manuals, product information, technical specications, and
declarations of conformance, please visit: www.StarTech.com/HB31C5A2CME
Package Contents
• USB Hub x 1
• 3.3 ft [1 m] USB-C to USB-C Locking Cable x 1
• 3.3 ft [1 m] USB-A to USB-C Locking Cable x 1
• Terminal Block Connector (Attached to the terminal block power adapter)
• Terminal block Power Adapter (NA, JP, UK, EU, ANZ) x 1
• Quick-Start Guide x 1
5
